2014-2019 Toyota Highlander Brake Light Switch Guide
If your Highlander won't start, shift out of park, or has brake lights acting up, the brake light switch is a likely and simple-to-fix culprit.
- A faulty brake light switch can prevent your Highlander from starting or shifting out of park, not just affect the brake lights.
- This is a simple, inexpensive, and very DIY-friendly repair that most owners can complete in under 30 minutes.
- High-quality aftermarket brands like Standard Ignition or Beck Arnley offer a reliable and cost-effective alternative to the OEM part.
- Before replacing the switch, always check the related fuse first to rule out a simpler problem.
Understanding the Brake Light Switch in Your Highlander
The brake light switch, also called a stop lamp switch, is a small but essential electronic sensor located at the top of your brake pedal arm. Every time you press the brake pedal, this switch sends a signal to multiple systems in your Highlander. On this generation of Toyota Highlander, a failing switch can cause a surprising number of issues that don't seem related to the brakes at first glance. Because it's tied into the push-to-start ignition and the automatic transmission's shift lock, a bad switch can leave you stranded.
Symptoms of a Bad Brake Light Switch
A failing brake light switch can cause several distinct problems. Pay attention to these common symptoms:
- Brake lights don't work or are stuck on: This is the most obvious sign. The lights may fail to illuminate when you press the pedal, or they might stay on constantly, draining your battery.
- Cannot shift out of Park: Your Highlander has a safety feature called a shift interlock that prevents you from shifting out of Park unless your foot is on the brake. If the switch is bad, the system doesn't get the signal and the shifter remains locked.
- Car won't start: For models with a push-button start, the vehicle requires a signal from the brake switch before the engine will turn over. A faulty switch can prevent the car from starting.
- Warning lights on the dash: A bad brake light switch can trigger the ABS, Traction Control (TRAC), or Vehicle Stability Control (VSC) warning lights, as these systems rely on the brake signal to function correctly. You may also see a Check Engine Light with code P0504.
- Cruise control issues: The cruise control system will not engage or will disengage unexpectedly if it receives an incorrect signal from the brake switch.
Known Issues & Recalls
While the 2014-2019 Highlander generation has not been subject to a specific brake light switch recall, earlier Toyota models were recalled for similar issues where silicone grease contaminated the switch contacts. No specific Technical Service Bulletins (TSBs) for the brake light switch were found for this year range, though some TSBs exist for other brake system components like pads and actuators.
Choosing an Aftermarket Brake Light Switch
For a part like a brake light switch, you don't always need to pay the premium for a dealership OEM part. A high-quality aftermarket switch can provide the same performance and reliability for less money. Here's a look at the brands available:
Tier 1: OEM Equivalents
- Standard Ignition (SMP): Widely regarded as a top-tier aftermarket manufacturer, often meeting or exceeding OEM quality. A very reliable choice.
- Beck Arnley: Known for sourcing parts from a network of global manufacturers, sometimes including the original OEM supplier. They focus on matching OE form, fit, and function.
- Vemo: A German brand with a strong reputation for electronic components and sensors, often considered OEM-quality for European cars and a solid choice for Japanese models.
Tier 2: Quality Aftermarket
- Holstein: A reputable brand that specializes in automotive sensors and electronic parts. A good, dependable mid-range option.
- Rostra Powertrain: With a history in transmission components and cruise control systems, Rostra has experience with vehicle electronics and offers a solid product.
Tier 3: Budget-Friendly
- Replacement / True Tech: These brands offer a cost-effective solution. While they may not have the long-standing reputation of the premium brands, they provide a functional part that meets basic requirements and can be a good option for budget-conscious repairs.
Pro-Tip: Check the Simple Things First
Before replacing the switch, check the fuse for the brake lights. A simple blown fuse can cause similar issues and is a much cheaper fix. Also, ensure your battery is in good health, as low voltage can cause a variety of electronic gremlins in modern vehicles.
Cost to Replace a 2014-2019 Highlander Brake Light Switch
This is a relatively inexpensive repair, whether you do it yourself or take it to a shop.
| Item | Estimated Cost |
|---|---|
| New OEM Part | $35 - $75 |
| New Aftermarket Part | $24 - $61 |
| Shop Labor | $87 - $143 |
| Total Professional Repair | $121 - $188 |
Frequently Asked Questions
Can I replace the brake light switch myself?
Yes, this is a very DIY-friendly job. The switch is located at the top of the brake pedal assembly and usually requires no special tools to replace. It typically twists and unplugs, or is held by a simple nut. The entire process can often be done in under 30 minutes.
Where is the brake light switch located on the Highlander?
You will find the brake light switch mounted to a bracket near the top of the brake pedal arm, under the dashboard. You will need to look up into the driver's side footwell to see it.
Will a bad brake light switch always cause a Check Engine Light?
Not always. While it can trigger a Check Engine Light with a code like P0504 (Brake Switch A/B Correlation), it's more common for other symptoms like the inability to shift from park or non-working brake lights to appear first.
What's the difference between a brake light switch and a brake sensor?
The terms are often used interchangeably for this part. On some very modern vehicles, there may be separate sensors for pedal position and the brake light circuit, but for the 2014-2019 Highlander, the brake light switch performs both functions.
Helpful Videos
Technical Specifications
OEM Part Numbers: 84340-0E020 84340-04030 84340-09310
Located on the brake pedal support. Typically a 4-pin connector. Functions as a dual-circuit switch for signal redundancy.
