A Mechanic's Guide to Front Disc Brake Hardware for the 2018-2022 Ford EcoSport
Eliminate brake noise and extend pad life by choosing the right front brake hardware for your EcoSport.
- This hardware is for the front disc brakes; most EcoSports have rear drum brakes which use different parts.
- Always replace your brake hardware when you install new brake pads to ensure quiet operation and even wear.
- For quiet performance, consider brands like Carlson that feature rubber-coated clips to reduce vibrations.
- In rust-prone areas, choose hardware with a corrosion-resistant coating for longer life.
Is Your Brake Hardware Failing?
Worn or missing brake hardware is a common cause of brake problems. The metal clips lose their spring tension over time due to heat and corrosion. This can lead to annoying noises and more expensive repairs down the road.
Key Symptoms of Bad Hardware:
- Squealing or Scraping: When clips are weak, brake pads can vibrate at high frequencies, creating a squeal when you apply the brakes. 🎬 Watch: How to fix brake squeaking and noise issues.
- Rattling or Clicking: Loose or missing clips can allow brake pads to rattle within the caliper bracket, especially over bumps or during low-speed braking.
- Uneven Brake Pad Wear: If hardware is corroded or not lubricated, pads can get stuck. This causes one pad to wear out much faster than the other.
Important Vehicle Safety Information
While there are no recalls for the front brake hardware itself, Ford issued a recall for 2018-2022 EcoSport models related to the engine. A failing oil pump belt could lead to a loss of engine oil pressure, which can cause a loss of power braking assist. This is a serious safety issue. Check with a Ford dealer to see if your vehicle is affected by recall 23S64.
Choosing the Right Aftermarket Hardware
When you replace your front brake pads, you should always install a new hardware kit. It’s a low-cost part that ensures your new pads work correctly. For an economy SUV like the EcoSport, quality aftermarket brands offer excellent performance and value.
Brand Quality Tiers
Based on owner feedback and mechanic consensus, here’s how the available brands stack up:
- Premium Aftermarket (Good for Quiet Operation & Durability):
- Raybestos: Widely regarded by mechanics as a top-tier aftermarket brand for brakes, known for consistent quality and reliability.
- Carlson: Specializes in brake hardware and promotes its QuietGlide® clips, which use a rubber coating to dampen vibration and reduce noise. A great choice if your primary concern is eliminating squeal.
- Standard Aftermarket (Excellent Value for Daily Driving):
- Centric: A major player in the brake industry, offering solid, reliable parts that are often considered equivalent to Raybestos.
- Dynamic Friction: A popular brand that offers good performance for the price. Their products are known to be low-dust and quiet for daily driving, though some users report the initial bite isn't as strong as OEM.
- Economy Aftermarket:
- Dorman: Dorman makes a vast range of parts. While some of their products are innovative, online feedback for their general quality can be mixed. It's a budget-friendly option, but other brands on this list have a stronger reputation specifically for brake components.
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket | $13.22 - $20.04 |
| New OEM (Motorcraft) | $25 - $45 |
| Shop Labor (as part of brake job) | $0 (typically included with pad replacement) |
Pro Tip: Check for Coated Hardware
If you live in an area with snow and road salt, look for hardware kits with a geometric or zinc coating. This coating helps prevent rust and corrosion, ensuring the clips and springs last longer and continue to function properly.
Frequently Asked Questions
Do I really need to replace the hardware with every brake job?
Yes. It is highly recommended. The old clips have been exposed to thousands of heat cycles and may have lost their tension. Reusing them can cause the same noise and wear problems you're trying to fix. For the low cost, it's cheap insurance for a quiet, effective brake job.
Is this hardware for the front or rear brakes?
This disc brake hardware kit is for the front wheels. Most 2018-2022 Ford EcoSport models are equipped with front disc brakes and rear drum brakes, which do not use this type of hardware. Some all-wheel-drive (AWD) trims may have rear disc brakes, which would use a different hardware kit. Always confirm your vehicle's specific setup.
What is included in a typical hardware kit?
A front kit for the EcoSport will typically include four abutment clips (two for each side) that install on the caliper bracket, and sometimes anti-rattle springs that fit onto the brake pads or caliper.
What happens if I don't replace the hardware?
You risk brake squeal, rattling noises, and accelerated, uneven wear on your new brake pads. The pads may not retract properly, causing them to drag on the rotor, which generates excess heat and can warp the rotor over time.
🎬 Watch: Full guide on changing EcoSport pads and rotors.Helpful Videos
Technical Specifications
OEM Part Numbers: GN1Z-2B121-A GN1Z-2B296-A
Kit for front disc brakes. Typically includes stainless steel abutment clips and anti-rattle springs.
