Ford F-150 Ignition Coil Guide: 2018-2024 Models
Experiencing a rough idle or engine misfires? Your F-150's ignition coils might be the culprit.
- For F-150s, especially EcoBoost models, using OEM Motorcraft ignition coils is strongly recommended by owners to prevent compatibility issues.
- Always replace spark plugs at the same time as ignition coils to ensure longevity and proper function.
- It is best practice to replace all coils at once, as they fail at similar rates.
- Replacement is easy on 5.0L/2.7L engines but requires more labor on the 3.5L EcoBoost due to intake manifold removal for passenger-side access.
Symptoms of a Failing Ignition Coil in a 2018-2024 F-150
When an ignition coil starts to fail on your F-150, the signs are usually noticeable. Because each cylinder has its own coil, a single failure can make the whole engine run poorly. Look out for these common symptoms:
- Check Engine Light: This is often the first sign. If the light is flashing, it indicates a serious misfire that could damage your catalytic converter. Pull over and have the code read as soon as possible.
- Engine Misfires: You might feel a shaking, stumbling, or hesitation from the engine, especially when accelerating or under load. This is often accompanied by diagnostic trouble codes like P0300 (random misfire) or P0301-P0308 (misfire on a specific cylinder). 🎬 Watch this video to see a severe EcoBoost misfire diagnosed.
- Rough Idle: Your truck may shake or vibrate more than usual when stopped at a light or in park.
- Reduced Power and Poor Acceleration: A truck that feels sluggish or won't accelerate like it used to can be a sign of a weak spark from a failing coil.
- Worse Fuel Economy: When a cylinder isn't firing correctly, your engine burns fuel less efficiently, and you'll notice more frequent trips to the gas station.
- Difficulty Starting: In severe cases where multiple coils have failed, the engine may crank but struggle to start, or not start at all.
Flashing Check Engine Light
A flashing check engine light signals a severe engine misfire. Continuing to drive can cause unburned fuel to enter the exhaust, potentially overheating and destroying your expensive catalytic converters. It is recommended to stop driving as soon as it is safe to do so.
Choosing the Right Aftermarket Ignition Coil
When shopping for new ignition coils, you'll find a wide range of brands and prices. For the 2018-2024 F-150, especially models with EcoBoost engines, the brand you choose matters. Forum discussions among F-150 owners consistently show that these trucks can be sensitive to coil quality.
Brand Tiers for the F-150
Tier 1: OEM & OEM-Equivalent
- Motorcraft (OEM): This is Ford's original part. Across owner forums, the overwhelming consensus is to stick with Motorcraft coils for the best reliability and to avoid troubleshooting headaches. Even owners of high-horsepower trucks often prefer OEM coils.
- Delphi & Hitachi: These are well-respected brands that manufacture parts for many automakers. They are often considered reliable, high-quality alternatives to OEM parts.
Tier 2: Performance Brands
- Granatelli & MSD: These brands market their coils as performance upgrades, often claiming increased voltage and horsepower gains. While some users may see benefits, others report issues. One owner documented a very negative experience with Granatelli coils, citing poor fitment and fragility that caused more problems. Many owners suggest that the potential for issues with performance coils outweighs the benefits for a daily driven truck.
Tier 3: Value Brands
- DriveWire, Standard Ignition, Spectra, Walker Products, Holstein, Global Parts: These brands offer a more budget-friendly price point. While they are designed to meet OE specifications, the long-term durability can be a gamble. Some owners have good luck, while others report premature failure or chasing misfire codes after installation. If the budget is tight, they can get you back on the road, but be aware that many experienced F-150 owners recommend saving up for an OEM or Tier 1 brand.
Known Issues & TSBs
For the 2018-2024 model years, there are no major recalls specifically for ignition coils. However, a Technical Service Bulletin (TSB) was issued for some 2021-2023 F-150 models equipped with the 3.5L PowerBoost engine that may experience reduced power and store misfire codes (P0301, P0302, P0303). Additionally, EcoBoost engines in general are known to be tough on spark plugs and ignition components, making quality parts even more important.
Pro Tip: Use Dielectric Grease
When installing new ignition coils, apply a small amount of dielectric grease to the inside of the coil boot where it meets the spark plug. This helps seal out moisture, prevents corrosion, and makes it easier to remove the coil in the future.
Installation & Cost
Replacing ignition coils is a common DIY job for many F-150 owners. The difficulty varies significantly by engine.
- 5.0L V8 & 2.7L EcoBoost: The coils are located right on top of the engine and are easily accessible. The job involves removing a single 8mm bolt and an electrical connector for each coil.
- 3.5L EcoBoost: The driver's side coils are easy to access, but the passenger side coils are located under the intake manifold. This makes the job more complex as the manifold must be removed to access them. 🎬 Watch a full tune-up walkthrough for the 3.5L EcoBoost engine.
| Engine | Est. Time | Difficulty |
|---|---|---|
| 5.0L V8 | 0.5 - 1 hour | Easy |
| 2.7L EcoBoost | 0.5 - 1 hour | Easy |
| 3.5L EcoBoost | 1.5 - 3 hours | Moderate |
Common Ordering Mistakes
For 2018+ 5.0L V8 engines, be aware that not all coils are the same. Cylinder #3 uses a remote-mounted coil with a short spark plug wire, while the other seven are standard coil-on-plug units. Double-check that you are ordering the correct parts for your specific cylinder if you are not replacing the full set.
Frequently Asked Questions (FAQ)
Should I replace all ignition coils at once?
It's highly recommended. Ignition coils are subjected to the same heat and wear cycles. If one has failed due to age and mileage, others are likely to fail soon. Replacing them all at once saves you from repeated repairs down the road. For the 3.5L EcoBoost, it is especially important to replace all passenger-side coils at the same time due to the labor involved in accessing them.
Should I replace my spark plugs at the same time?
Yes, absolutely. It's considered best practice to replace spark plugs whenever you replace ignition coils. A worn or incorrectly gapped spark plug can cause a new ignition coil to fail prematurely. Since you've already done most of the labor to access them, installing new plugs is a smart and cost-effective move.
Are performance ignition coils worth it for my F-150?
For most owners, the answer is no. While brands like MSD and Granatelli claim performance gains, the F-150's stock ignition system is very robust. Many owners in online forums report that aftermarket performance coils can introduce new problems like misfires and reliability issues, recommending sticking with OEM Motorcraft coils for proven performance.
What causes ignition coils to fail?
Coil failure is most commonly caused by age and heat cycles. Over time, the internal windings can break down. Other causes include excessive vibration, moisture intrusion, or damage from worn-out spark plugs 🎬 See how to test an ignition coil with this guide. that create excessive resistance.
Helpful Videos
Technical Specifications
OEM Part Numbers: JL3Z-12029-A FT4Z-12029-A JL3Z-12029-B
All 2018-2024 Ford F-150s use a coil-on-plug ignition system. Each cylinder has one ignition coil. The 5.0L V8 has 8 coils, while the 2.7L and 3.5L V6 engines have 6 coils.
