2012-2014 Nissan GT-R Steering Column: Diagnosing Lock Failures and Loose Wheels
This guide covers the most common issues for the R35 GT-R steering column, from electronic lock failures that prevent the car from starting to the notorious loose column bracket problem.
- The most critical failure is the Electronic Steering Column Lock (ESCL), which can leave you stranded with a no-start condition.
- A loose, wobbly steering column is a major safety hazard caused by failed internal brackets and should be addressed immediately.
- An airbag light combined with non-working steering wheel buttons almost certainly means the clock spring has failed, disabling the driver's airbag.
- Replacement is complex and not recommended for DIYers due to the airbag system and tamper-proof bolts on the ESCL module.
Known Issues for the 2012-2014 Nissan GT-R Steering Column
While the R35 GT-R is a robust performance machine, its steering column has several well-documented weak points. Understanding these specific issues is key to proper diagnosis and repair.
Electronic Steering Column Lock (ESCL) Failure
This is one of the most common and frustrating issues for R35 owners. The primary symptom is a car that refuses to start. When the ESCL module fails, it does not send the correct signal to the Body Control Module (BCM), and the ignition will not activate—the start button will be unresponsive, and the steering wheel remains locked. This is often caused by a malfunction within the lock unit itself. While Nissan issued a voluntary service campaign (NTB13-014) for this issue on earlier 2009-2011 models, the same failure can occur on 2012-2014 vehicles.
Pro Tip: If you are stranded with a failed ESCL, some owners have had temporary success by lightly tapping the ESCL module (a small box on the side of the steering column) with the handle of a screwdriver to try and un-stick the internal mechanism. This is not a permanent fix but may allow you to start the car one more time 🎬 See this walkthrough on how to fix the steering lock. to get it to a repair shop.
Clock Spring (Spiral Cable) Failure
If your airbag warning light is illuminated on the dash, or if your steering wheel-mounted controls (like the horn, radio buttons, or cruise control) have stopped working, the clock spring is the most likely culprit. The clock spring is a coiled ribbon of wires that can wear out and break from the constant turning of the steering wheel. This is a critical safety issue, as a failed clock spring means the driver's airbag will not deploy in a collision.
Loose or "Flopping" Steering Column Brackets
A particularly alarming issue, especially on cars driven aggressively or on a track, is the failure of the factory brackets that hold the tilt and telescoping assembly. These thin, stamped-metal brackets can bend or break, causing the entire steering column to become loose and literally flop in the driver's lap. This presents an extreme safety hazard. The immediate symptom is excessive play or movement in the entire column assembly, which will feel disconnected from the dashboard. Aftermarket reinforcement braces are available to permanently fix this design weakness.
🎬 Watch: How to fix a loose or flopping steering column.Steering Column Bearing Failure (2009 Recall Context)
Nissan issued a safety recall (NHTSA #15V040) for 2009 GT-R models due to a manufacturing defect where the steering column's outer tube could stress and fracture an upper bearing retainer. Symptoms included grinding noises, excessive looseness in the steering wheel, and, in a worst-case scenario, a complete loss of steering. While this recall does not apply to 2012-2014 models, the symptoms are valuable to know, as similar bearing failures can occur from wear and tear.
Symptoms of a Failing Steering Column
| Symptom | Likely Cause | Severity |
|---|---|---|
| Car will not start, steering wheel is locked, no response from ignition button. | Electronic Steering Column Lock (ESCL) failure. | Critical (Stranded) |
| Airbag / SRS warning light is on. | Clock spring failure. | Critical (Airbag disabled) |
| Horn, cruise control, or radio buttons on steering wheel do not work. | Clock spring failure. | Moderate |
| Entire steering column feels loose, wobbles, or moves excessively. | Failed/bent mounting brackets. | Critical (Loss of control risk) |
| Grinding or scraping noise when turning the wheel. | Worn internal steering column bearing. | Serious |
| Steering feels stiff or binds when turning. | Worn U-joint in the steering shaft or damaged internal bearing. | Serious |
Buying a Used 2012-2014 GT-R Steering Column
Given the high cost of a new column, a used OEM unit is often a smart choice. However, due to the known issues, careful inspection is crucial.
What to Check Before You Buy
- Verify the Part Number: The main assembly should be part number 48810KB61A. Ensure it's the correct part for your vehicle.
- Inspect for Physical Damage: Look for any signs of bending, cracking, or damage to the main column shaft and mounting points. A column from a vehicle in a major front-end collision should be avoided.
- Check the Connectors: All electrical connectors should be intact and free of corrosion or broken pins. Damaged wiring can be very difficult to repair.
- Ask About the ESCL: Ask the seller if the steering lock was functional when removed. If you buy a column with a locked ESCL, you will not be able to install it. Be prepared to potentially replace the ESCL module (Part D8700-JF00D) on any used column as a preventative measure.
- Assume the Clock Spring is a Wear Item: It is difficult to test a clock spring on a removed column. It's wise to budget for a new clock spring (Part 25560KB50A) or transfer your old one if it's still good. 🎬 Watch: Step-by-step guide to removing the steering wheel and paddles.
- Examine the Mounting Brackets: Specifically look at the brackets for the tilt/telescope mechanism. Check for any signs of stress, bending, or cracks, which would indicate the "loose column" issue.
Cost Comparison
Prices for the GT-R steering column and its components can be high, reflecting the car's high-performance nature. All prices are estimates and can vary by supplier and location.
| Part / Service | Estimated Cost |
|---|---|
| New OEM Steering Column Assembly (48810KB61A) | $1,500 - $2,000+ |
| New OEM Clock Spring / Multi-Function Switch | $950 - $1,400 |
| Used OEM Steering Column Assembly | $400 - $800 |
| New OEM ESCL Module (D8700-JF00D) | $450 - $600 |
| Shop Labor for Replacement | $400 - $700 |
Replacement Difficulty
- Difficulty Rating: 4 out of 5 (Difficult)
- DIY Feasible: Not recommended for beginners.
Replacing the steering column is a complex job. It requires removing dashboard panels, the instrument cluster, and most importantly, the driver's airbag. Mishandling an airbag can be extremely dangerous. Furthermore, the ESCL module is often secured with tamper-resistant bolts that must be drilled out for removal. After installation, a diagnostic tool may be needed to clear fault codes and recalibrate the steering angle sensor. This job is best left to experienced mechanics or a certified Nissan GT-R technician.
Frequently Asked Questions (FAQ)
Why won't my GT-R start and the steering wheel is stuck?
This is the classic symptom of a failed Electronic Steering Column Lock (ESCL) module. The module is not signaling to the car's computer that it is safe to start the engine. The module will likely need to be replaced.
Why is my airbag light on and my horn doesn't work?
This combination of symptoms almost always points to a failed clock spring (also called a spiral cable) inside the steering column. The internal wires have broken, cutting the connection to the airbag and steering wheel buttons. This is a critical safety failure that should be addressed immediately.
Is it safe to drive with a steering wheel that feels loose or wobbly?
No, it is not safe. A loose-feeling steering column on an R35 GT-R could be a sign of failing mounting brackets. If these brackets break completely, the steering wheel can drop into your lap, leading to a total loss of steering control. The vehicle should be inspected immediately.
Does a replacement steering column need to be programmed?
The column itself is a mechanical part and does not require programming. However, components attached to it might. The ESCL is linked to the vehicle's anti-theft system, and while a direct replacement usually works, some cases may require dealer tools. Additionally, after any work on the column, the Steering Angle Sensor (SAS) should be recalibrated to ensure the Vehicle Dynamic Control (VDC) system functions correctly.
Helpful Videos
Technical Specifications
OEM Part Numbers: 48810KB61A 25560KB50A D8700-JF00D
The assembly includes the main column structure, power tilt/telescope motors, Electronic Steering Column Lock (ESCL) module, and houses the clock spring/spiral cable.
