2013-2019 Cadillac XTS Sun Visor: Matching Suede & Cloth, and Fixing Vanity Lights
This guide covers common failures like drooping and vanity light problems, and explains how to match the correct material and color for your XTS interior.
- The biggest challenge is matching the interior; locate your RPO trim code on the sticker in the glove box to ensure you buy the correct color and material (suede vs. cloth).
- Common failures include the visor drooping from a worn pivot and the vanity light failing due to a bad internal switch or wire.
- Replacement is a very simple DIY task that takes about 15 minutes with only a screwdriver.
- New aftermarket visor assemblies are not readily available, making high-quality used OEM parts the best value for replacement.
Symptoms of a Failing Cadillac XTS Sun Visor
A faulty sun visor can be more than just a cosmetic issue; it can become a daily annoyance and even a safety hazard. Here are the most common signs that your XTS sun visor needs replacement.
1. Visor Droops or Won't Stay Up
The most frequent complaint is a visor that sags or droops, obstructing your view. The internal pivot mechanism, which holds the visor in place against the headliner, can wear out over time. This causes the visor to lose its tension, allowing it to fall down with the slightest bump in the road. This is not only distracting but can also be a safety risk if it blocks your vision unexpectedly.
2. Vanity Mirror Light Fails or Flickers
If the light around the vanity mirror doesn't turn on, flickers, or only works when the visor is in a specific position, the problem is usually within the visor itself. The issue is often a faulty switch that is activated when you slide the mirror cover open, or a break in the wiring that runs through the visor's pivot point. While it could be a blown fuse, if other interior lights work, the visor's internal wiring or switch is the likely culprit.
3. Cracked Mirror or Broken Cover
Physical damage from impacts or age can lead to a cracked vanity mirror or a broken mirror cover. A broken cover can prevent the vanity light from turning on or off correctly. In some cases, a faulty switch can cause the light to stay on even when the cover is closed, leading to a drained battery over time.
Part Variants: Matching Your XTS Interior
Cadillac offered several interior options for the XTS, making it critical to match your replacement visor correctly. Ordering the wrong one can result in a noticeable mismatch in your car's premium interior.
- Material: The two primary materials used were a standard cloth and a premium suede (often found in Platinum trims). Visually inspect your current visor to determine which material you have.
- Color: Common colors include Jet Black, Shale (a light tan/beige), and Titanium (a light grey). Do not guess the color name based on appearance, as names like "Shale," "Cocoa," and "Cashmere" can look similar online but are different.
- Features: All XTS visors came with an illuminated vanity mirror. Ensure your replacement has the correct electrical connector.
Pro Tip: The best way to guarantee a perfect match is to find your vehicle's interior trim code. This is located on the Service Parts Identification (RPO code) sticker. In your Cadillac XTS, this sticker is most often found inside the glove box or in the trunk, sometimes on the spare tire cover. The trim code is typically a three-character code (e.g., 4B8 for Beige) found on the bottom of the sticker.
Buying a Used Sun Visor for Your 2013-2019 XTS
Since new aftermarket sun visor assemblies for the XTS are generally not available, a quality used OEM part is the most cost-effective solution. A used original part guarantees perfect fitment and material quality compared to non-existent or low-quality aftermarket options. Here’s what to look for:
- Verify the Part: Always provide the seller with your vehicle's year and, if possible, the interior trim code to confirm a match. Request clear photos of the visor from all angles to check for stains, tears, or damage.
- Inspect the Pivot: Ask the seller to confirm that the visor's pivot is stiff and holds its position firmly. A loose pivot on a used part means it will likely droop in your car as well.
- Check the Connector: Look at photos of the electrical connector to ensure it matches yours and is not damaged. Some sellers on eBay note when a connector is missing or cut.
- Mirror and Light: Confirm that the mirror is not cracked and the sliding cover moves smoothly. While the seller may not be able to test the light, a physically intact mirror assembly is a good sign.
Warning: Be careful to distinguish between the windshield sun visor and the panoramic sunroof's retractable sun *shade*. The sunroof shade is a much more complex and expensive part that is 🎬 See this walkthrough for replacing the Cadillac sunroof shade assembly known to fail due to weak plastic components in its roller mechanism. This guide specifically 🎬 Watch: A better-than-OEM fix for the panoramic sunroof sunshade covers the windshield visors.
Cost Comparison for a Cadillac XTS Sun Visor
| Part Type | Estimated Cost | Notes |
|---|---|---|
| New OEM | $100 - $250 | Prices vary by color and supplier. Ensures a perfect, brand-new part but is the most expensive option. |
| New Aftermarket | Not Available | Complete aftermarket visor assemblies for this specific model are not commonly available from major brands as of early 2026. |
| Used OEM | $50 - $120 | The most popular and cost-effective option. Prices vary based on condition, color, and seller. |
| Shop Labor | $50 - $100 | Most shops will charge a minimum of 0.5 hours for this simple replacement. |
Step-by-Step Replacement Guide
Replacing the sun visor on a 2013-2019 XTS is a simple DIY job that typically takes less than 15 minutes and requires basic tools.
- Position the Visor: Unclip the visor from the center headliner clip and swing it towards the side window to get better access to the mounting point.
- Remove the Trim Cover: At the base of the visor's pivot point, there is a small plastic cover. Use a small flathead screwdriver or a trim removal tool to gently pry this cover off. It will expose the mounting screws.
- Unscrew the Mount: Using a Phillips or Torx screwdriver (commonly a T20 or T25 size), remove the two or three screws holding the visor's mounting bracket to the roof structure. Hold the visor with one hand as you remove the last screw to prevent it from falling.
- Disconnect the Electrical Connector: Gently pull the visor down from the headliner. You will see a small wiring harness. Depress the tab on the connector and pull it apart to disconnect the power for the vanity light.
- Install the New Visor: Connect the electrical plug on the new visor. Position the mounting bracket into the recess in the headliner, aligning it with the screw holes. Hand-thread the screws to avoid cross-threading, then tighten them until snug. Do not overtighten, as this can crack the plastic bracket.
- Reinstall the Cover: Snap the plastic trim cover back into place over the mounting bracket. Test the visor's movement and the function of the vanity light.
Known Issues, Recalls, and TSBs
As of early 2026, there are no specific recalls or Technical Service Bulletins (TSBs) issued by GM or the NHTSA for the sun visors on the 2013-2019 Cadillac XTS. Any failures are typically due to normal wear and tear of the interior components.
Frequently Asked Questions (FAQ)
Can I fix my drooping sun visor without replacing it?
Some DIY fixes exist for other models, such as wrapping the pivot bar with material to increase friction, but these are often temporary. The internal mechanism is not designed to be serviced, and the most reliable and long-lasting solution is to replace the entire visor assembly.
Why did my vanity light stop working?
The most common cause is a failure in the small switch activated by the mirror cover or a break in the wire that flexes every time you move the visor. You can check the fuse for the interior lights first, but if other lights work, the problem is almost certainly inside the visor itself.
Is the driver's side visor the same as the passenger's side?
No, they are mirror images of each other and are not interchangeable. They have different part numbers and are sold specifically for the left (driver) or right (passenger) side.
How do I find my interior color code?
Look for the Service Parts Identification sticker, which is usually a silver or white label located inside the glove compartment. On some GM vehicles, it may be in the trunk near the spare tire. The interior trim code is a three-character code located near the bottom of the list of codes on the sticker.
Helpful Videos
Technical Specifications
OEM Part Numbers: 15804773 20996309 20996310 22935272 22935274 22980905 22980911 22796256 22980915 22796260
Features an illuminated vanity mirror with an integrated on/off switch in the mirror cover. Attaches to the headliner via a primary pivot mount and a secondary clip.
