Audi A6 Quattro Wheel Bearing Replacement

Wheel Bearing Axle Nut Torque Spec: M14 bolt - 85 ft-lbs / 115Nm, M16 bolt - 140 ft-lbs / 190Nm. Turn additional 180 degrees for both.

Wheel Bearing Axle Nut Torque Spec: 147 ft-lbs / 200Nm, Turn additional 90 degrees after tightening

75mm O.D.

75mm OD

FAG Global Number 800941C

Grade: Aftermarket With OE No. 4B0598625B

FAG Global Number 567447B

82mm O.D. 43/45mm I.D. This is a Stepped (Two Different Inner Diameters) Wheel Bearing. 43mm and 45mm ID. Stepped Areas, Width 23mm w/43mm ID and 13mm Width w/45mm ID. Overall Bearing Width 37mm and 82mm Outer Diameter.

Grade: Aftermarket Dimensions: 82 mm

with 1.5354 in. Bearing Inside Diameter with 2.9527 in. Outside Diameter Bearing(s) 2.9527 in. Width ; Sealed

with 1.771 in. Bearing Inside Diameter with 3.346 in. Outside Diameter Bearing(s) 1.584 in. Width ; Sealed

FAG Global Number 101007

FAG Global Number 713 1317 100

Repair Kit

Grade: Aftermarket Description: For vehicles with ABS

with 1.6929 in. Bearing Inside Diameter with 3.2283 in. Outside Diameter Bearing(s) 3.2283 in. Width ; Sealed

82mm O.D. 43/45mm I.D. This is a Stepped (Two Different Inner Diameters) Wheel Bearing. 43mm and 45mm ID. Stepped Areas, Width 23mm w/43mm ID and 13mm Width w/45mm ID. Overall Bearing Width 37mm and 82mm Outer Diameter.

82mm O.D. 43/45mm I.D. This is a Stepped (Two Different Inner Diameters) Wheel Bearing. 43mm and 45mm ID. Stepped Areas, Width 23mm w/43mm ID and 13mm Width w/45mm ID. Overall Bearing Width 37mm and 82mm Outer Diameter.

FAG Global Number 101645

A6 Quattro

FAG Global Number 563438A1

Grade: Aftermarket

Grade: Aftermarket Description: For vehicles with ABS With OE No. 4F0498625B

with module

Grade: Aftermarket Description: For vehicles with ABS
