Buick LeSabre Wheel Seal Replacement

8.875" Ring Gear Pontiac Axle

2.000 Shaft Diameter 2.560 Bore Diameter 2.565 Outside Diameter Seal 0.224 Width

1.399 Shaft Diameter 2.292 Bore Diameter 2.296 Outside Diameter Seal 0.469 Width

1.618 Shaft Diameter 2.575 Bore Diameter 2.579 Outside Diameter Seal 0.500 Width with 8.875 Ring Gear ; w/o 9.5" X 2" Brks.

FAG Global Number 413 3045 100

Chev. Design 7.50",8.50" Ring Gear FAG Global Number 413 2468 100 1.399" Shaft

Wagon

8.75 in. Ring Gear

8.875" Ring Gear w/o 9.5" X 2" Brks. Brake Shoe FAG Global Number 413 2698 100 .70" Wide Brg. .830" Wide Brg. 1.024" Wide Brg.

1.500 Shaft Diameter 2.502 Bore Diameter 0.313 Width

2.000 Shaft Diameter 2.562 Bore Diameter 2.566 Outside Diameter Seal 0.335 Width

FAG Global Number 413 2577 100 2.506" O.D.

1.688 Shaft Diameter 2.551 Bore Diameter 2.556 Outside Diameter Seal 0.470 Width ; B, O Axles

2.000 Shaft Diameter 2.962 Bore Diameter 2.966 Outside Diameter Seal 0.250 Width

FAG Global Number 413 3036 100

2.125 Shaft Diameter 2.763 Bore Diameter 2.767 Outside Diameter Seal 0.250 Width

FAG Global Number 413 3731 100

B,O Axles FAG Global Number 413 2738 100 1.688" Shaft

FAG Global Number 413 3061 100

1.875 Shaft Diameter 2.868 Bore Diameter 2.872 Outside Diameter Seal 0.544 Width ; B, O Axles

1.524 Shaft Diameter 2.714 Bore Diameter 2.718 Outside Diameter Seal 0.500 Width 2nd Design

2nd Design 0.5 (in) Width 2.718 (in) Outside Diameter

FAG Global Number 413 2383 100

FAG Global Number 413 2593 100
