Chevrolet Astro Drive Axle Shaft Seal Replacement

1.248 Shaft Diameter 2.044 Bore Diameter 2.050 Outside Diameter Seal 0.378 Width

FAG Global Number 413 2326 100

with 7.25 (in) Ring Gear with GMC Axle Carrier Unit Independent

1.574 Shaft Diameter 2.716 Bore Diameter 2.720 Outside Diameter Seal 0.531 Width

GM 7.5 in. and 7.6 in.

FAG Global Number 413 2607 100

with 7.25 (in) Ring Gear with AAM Axle Independent Front Suspension

GM 7.5 GM 7.5 in. and 7.6 in.

GM 7.2 in. IFS Inner Side Seal GM 7.2 in.; IFS~Inner axle seal; 2.718 in. O.D.

GM 7.2 in. IFS; Stub Axle Seal GM 7.2 in.; IFS
