Chevrolet Bel Air Engine Valve Lifter Replacement

Hydraulic High Revolution Engines Box of 128

Hydraulic Lifter

Mechanical Box of 128

Mechanical

Hydraulic High Revolution Engines

Mechanical Lifter

Second Design Without Machined Line

Use With CCS-5 Camshaft

Use With CCS-1 And CCS-12 Camshafts

Part Application Notes Replaces BB969RF16 .842 Inch Retro-Fit Hydraulic Roller Lifter Use With 22141, 22236 Camshafts Up to 6,500 RPM Capability .120 Inch Plunger Travel, .700 Inch Wheel Diameter Recommended Spring Pressures Are 100-180 Lbs Seat Pressure And 280-380 Lbs Open Pressure Contains 16 Lifters With Vertical Tie Bar

.842 Inch Retro-Fit Hydraulic Roller Lifter Use With 22141, 22236 Camshafts Up to 6,500 RPM Capability .120 Inch Plunger Travel, .700 Inch Wheel Diameter Recommended Spring Pressures Are 100-180 Lbs Seat Pressure And 280-380 Lbs Open Pressure Contains 16 Lifters With Vertical Tie Bar

.842 Inch Retro-Fit Hydraulic Roller Lifter Use With 22238, 22398 Camshafts Up to 6,500 RPM Capability .120 Inch Plunger Travel, .700 Inch Wheel Diameter Recommended Spring Pressures Are 100-180 Lbs Seat Pressure And 280-380 Lbs Open Pressure Contains 16 Lifters With Vertical Tie Bar

Part Application Notes Replaces SB079RF16 .842 Inch Retro-Fit Hydraulic Roller Lifter Use With 22238, 22398 Camshafts Up to 6,500 RPM Capability .120 Inch Plunger Travel, .700 Inch Wheel Diameter Recommended Spring Pressures Are 100-180 Lbs Seat Pressure And 280-380 Lbs Open Pressure Contains 16 Lifters With Vertical Tie Bar

Body Dia. 0.842in.; Brg. Dia. 0.750in.; 7.781 in .L; Steel A Body 8-Centerline/4ea.-0.180in. Offset Left/Right; 203HG Series Push Rod Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses

BodyDia.0.842in.; Brg.Dia. 0.75in.; 8.281in.Int./9.25in.Ex.L; SteelABody 8-Centerline/4ea.-0.180in.Offset Left/Right; 20396 Std. L PushRod Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses

Body Dia. 0.842in.; Brg. Dia. 0.750in.; 6.150 L; Alum. Top C Body Centerline; 1235L350 Push Rod; 1300LRK Rev Kit Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses

Body Dia. 0.842in.; Brg. Dia. 0.750in.; 7.781 in. Length; Steel B Style Body Centerline Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses

Body Dia. 0.842in.; Brg. Dia. 0.750in.; 8.281 in. Int.9.250 in. Ext. L; Steel B Body Centerline; 20396 Std. Length Push Rod Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses

Body Dia. 0.842in.; Brg. Dia. 0.750in.; 7.781 in. L; Steel A Body 8ea.-0.180in. Offset Left/Right; 203HG Series Push Rod Requires Roller Camshaft~w/Splayed Valve Or SB2 Head~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses~Small Block Chevy V-8 w/Splayed Valve Or SB-2 Head

BodyDia. 0.842in.; Brg.Dia. 0.75in.; 6.15in.L; Alum.TopCBody 8-Centerline/4ea.-0.185in.Offset Left/Right; 1235L350 PushRod; 1350LRK RevKit Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses

Body Dia. 0.842in.; Brg. Dia. 0.750in.; Steel A Body Centerline; 20396 Series Push Rod Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses

Body Dia. 0.842in.; Brg. Dia. 0.750in.; 6.500 in. L; Alum. Top C Body Centerline; 1235L Push Rod; 200LRK/300LRK Rev Kit Requires Roller Camshaft

Body Dia. 0.842in.; Brg. Dia. 0.750in.; 7.781 in. L; Steel A Body Centerline Lightweight Version; 203HG Std. Length Push Rod Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses

BodyDia. 0.842in.; Brg.Dia. 0.750in.; 6.5in. L; Alum. TopC Body 8-Centerline/4ea.-0.185in. Offset Left/Right; 1235L PushRod; 150LRK RevKit Requires Roller Camshaft

BodyDia.0.842in.; Brg. Dia.0.75in.; 6.5in. L; Alum. Top C Body 8-Centerline/4ea.-0.150in. Offset Left/Right; 1235L Push Rod; 150LRK RevKit Requires Roller Camshaft

Body Dia. 0.903in.; Brg. Dia. 0.810in.; Steel A Body Centerline Lightweight Version; 203HG Series Push Rod Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses

Body Dia. 0.903in.; Brg. Dia. 0.810in.; Steel A Body Centerline Lightweight Version; 20396 Series Push Rod Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses

BodyDia. 0.903in.; Brg.Dia. 0.810in.; Steel A Body 8-Centerline/4ea.-0.180in. Offset Left/Right; 20396 Series Push Rod Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses

Body Dia. 0.903in.; Brg. Dia. 0.810in.; Steel A Body 8-Centerline/4ea-0.180in. Offset Left/Right; 203HG Series Push Rod Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses

Body Dia. 0.936in.; Brg. Dia. 0.850in.; Steel A Body Centerline Lightweight Version; 20396 Series Push Rod Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses

Body Dia. 0.936in.; Brg. Dia. 0.850in.; Steel A Body Centerline Lightweight Version; 203HG Series Push Rod Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses

BodyDia. 0.936in.; Brg.Dia. 0.850in.; Steel A Body 8-Centerline/4ea.-0.180in. Offset Left/Right; 20396 Series Push Rod Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses

BodyDia. 0.936in.; Brg. Dia. 0.850in; Steel A Body 8-Centerline/4ea.-0.180in. Offset Left/Right; 203HG Series Push Rod Requires Roller Camshaft~Extra Tall Version To Fit Late Bow-Tie Blocks~w/Raised Lifter Bosses
