Chevrolet C3500 Drive Shaft Center Support Bearing Replacement

Cushion Only

with 1.50in Mounting with 38mm Mounting Bearing Not Included

with 1.1811in & 30mm Inside Diameter Bearing(s) 3.50in Center Line Of Bearing To Mounting Face 89mm Center Line Of Bearing To Mounting Face with 1.50in Mounting with 38mm Mounting with Spicer Series 1280, 1310 accepted Slip Yoke Style Complete Assembly

Bearing not Included Contains Rubber Piece only

with 1.3780in & 35mm Inside Diameter Bearing(s) 2.28in Center Line Of Bearing To Mounting Face 58mm Center Line Of Bearing To Mounting Face with 168mm Mounting with 6.62in Mounting with Spicer Series 1280, 1310, 1350, 1410 accepted Slip Yoke Style

with 1.5750in & 40mm Inside Diameter Bearing(s) 2.48in Center Line Of Bearing To Mounting Face 63mm Center Line Of Bearing To Mounting Face with U-Shaped Bracket with 168mm Mounting with 6.62in Mounting with Dust Shields with Spicer Series 1410, 1480 accepted

without Mounting Studs with 1.5750in & 40mm Inside Diameter Bearing(s) 2.28in Center Line Of Bearing To Mounting Face 58mm Center Line Of Bearing To Mounting Face with Mounting Holes with 168mm Mounting with 6.62in Mounting with Cleveland O Shaft

Spicer 1330, 1350, 1410, 1480 Series 1.5748" Bearing I.D. End Yoke Style

Spicer 1410 Series 1.5748" Bearing I.D.

Spicer 1280, 1310, 1330, 1410 Series 1.3780" Bearing I.D. Slip Yoke Style Optional with slingers

Spicer 1330,1350,1410,1480 U-joint Series,w/40mm End Yoke FAG Global Number 713 0158 100 w/o Slinger 2.3" Ctr Hght, 1.57" I.D. w/o Slngr Bearing Lenght 34,1310-1550 Series U-Joints

Replaces OE Part Number(s) 12377849, 12546071, 15512198 with 1.574in Bearing Inside Diameter

Spicer 1280, 1310, 1330 - 1.38 in. I.D. Bearing Assembly

40mm ID - 22mm Width - 57mm Centerline Height - 168mm Bolt Hole Center - 2 Slingers 2 Slingers Both Same

Spicer 1280, 1310, 1330 and 1410 U-joint Series w/35mm End Yoke FAG Global Number 713 0152 100

Replaces OE Part Number(s) 12377849, 12546071, 15512198 with 1.574in Bearing Inside Diameter

Slip Yoke Style with 1.378 (in) Bearing Inside Diameter with 35 (mm) Bearing Inside Diameter with Spicer 1280,1310,1330,1410 U-Joint(s)

Spicer 1280, 1310, 1330 - 1.38 in. I.D. Bearing Only

w/Spicer Axle

Spicer 1410 - 1.57 in., I.D. - 2.25 in. Height

FAG Global Number 713 0160 100

40mm ID - 22mm Width - 57mm Centerline Height - 168mm Bolt Hole Center - 2 Slingers 2 Slingers Each Different

Spicer Axle FAG Global Number 713 0159 100

Kit

1.889 in. Width with 1.377 in. Bearing Inside Diameter with 4.299 in. Outside Diameter Bearing(s) 6.614 in. Bolt Hole Centers ; w/ 2 Piece Drive Sh.

1.375" Rr. Brg. I.D. FAG Global Number 713 0156 100 1.375" I.D.

Kit

w/2 Piece Drive Shaft, 1.375" I.D. FAG Global Number 713 0169 100 1.378" I.D. Flat Brkt. w/ 1.378" I.D.

35mm ID - 25mm Width - 55.9mm Centerline Height - 168.2mm Bolt Hole Center - 0 Slingers
