Chevrolet Express 2500 Drive Shaft Pinion Yoke Replacement

Dana 60/Reverse Driveshaft at FrontAxle or Rear Driveshaft at RearAxle Dana Super 60; Front Driveshaft at FrontAxle or Rear Driveshaft at RearAxle

9.5 in. 14 Bolt; 8.6 in. 10 Bolt Driveshaft at Rear Axle; To Use Triple Lip Pinion Seal GM 9.5 in.; 14 bolt cover; Rear Driveshaft at Rear Axle; To Use Triple Lip Pinion Seal~GM 9.5 in.; Triple Lip Pinion Seal Sleeve; 2.110 in. Hub Diameter; Installs onto 1.940 in. Yoke Hub

10.5 in. 14 Bolt; 11.5 in. Driveshaft At Rear Axle; To Use w/Triple Lip Seal GM 10.5 in.; Triple Lip Pinion Seal Sleeve; To Use w/Triple Lip Seal; 2.370 in. Hub Diameter; Installs onto 2.200 in. Yoke Hub~GM 10.5 in; 14 Bolt Cover; Rear Driveshaft At Rear Axle; To Use w/Triple Lip Seal

For Use w/GM 7.2 in./7.625 in./8.0 in. Triple Lip Pinion Seal GM 7.2 in. IFS; Triple Lip Pinion Seal Sleeve; To Use w/Triple Lip Seal; 1.690 in. OD Hub Diameter; Installs onto 1.522 in. Yoke Hub~GM 7.2 in.; IFS

Dana 60/Reverse/44; For Use w/1350 U-Joint; Strap Style; 3.219 in. Snap Ring Span; 1.062 in. Cap Diameter; Outside Snap Ring Dana 60; Pinion Yoke; For Use w/1310 U-Joint; Strap Style; 3.219 in. Snap Ring Span; 1.062 in. Cap Diameter; Outside Snap Ring~Dana Super 60; For Use w/1350 U-Joint; Strap Style; 3.219 in. Snap Ring Span; 1.062 in. Cap Diameter; Outside Snap Ring

Dana 60/Reverse/44 Driveshaft at Front Axle or Rear Driveshaft at Rear Axle; For Use w/1330 U-Joint; U-Bolt Style Dana Super 60; Front Driveshaft at Front Axle or Rear Driveshaft at Rear Axle; For Use w/1330 U-Joint; U-Bolt Style~Dana Super 60; Pinion Yoke; 29 Spline; U-Bolt Style; For Use w/1330 U/Joint; 1.063 in. Cap Diameter; 3.625 in. Span

10.5 in. 14 Bolt Driveshaft At Rear Axle GM 10.5 in. 14 Bolt Rear; Pinion Yoke; Strap Style; For 1485 Series U-Joint; 1.375 in. Cap Diameter; 4.181 in. Span~GM 10.5 in; 14 Bolt Cover; Rear Driveshaft At Rear Axle

9.5 in. Axle Driveshaft at Rear Axle; 1415 U/Joint Size GM 9.5 in. 14 bolt; Rear Pinion Yoke; 30 Spline; Strap Style; For 1415 U/Joint Size; 1.188 in. Cap Diameter; 4.181 in. Span~GM 9.5 in.; 14 bolt cover; Rear Driveshaft at Rear Axle; 1415 U/Joint Size

Dana 60/70; Front Driveshaft at Front Axle or Rear Driveshaft at Rear Axle; Replacement; w/1330 U/Joint Size Dana Super 60; Front Driveshaft at Front Axle or Rear Driveshaft at Rear Axle; Replacement; w/1330 U/Joint Size~Dana Super 60; Pinion Yoke; 29 Spline; Strap Style; For Use w/1330 U/Joint; 1.063 in. Cap Diameter; 3.625 in. Span

Dana 60/Reverse; For Use w/1350 U-Joint; Strap Style; 3.625 in. Snap Ring Span; 1.188 in. Cap Diameter; Outside Snap Ring Dana Super 60; For Use w/1350 U-Joint; Strap Style; 3.625 in. Snap Ring Span; 1.188 in. Cap Diameter; Outside Snap Ring~Dana Super 60; Pinion Yoke; 29 Spline; Strap Style; For Use w/1350 U/Joint; 1.188 in. Cap Diameter; 3.625 in. Span

Dana 60/Reverse Driveshaft at Front Axle or Rear Driveshaft at Rear Axle; For Use w/1350 U-Joint; U-Bolt Style; Forged Steel Dana Super 60; Front Driveshaft at Front Axle or Rear Driveshaft at Rear Axle; For Use w/1350 U-Joint; U-Bolt Style; Forged Steel~Dana Super 60; Pinion Yoke; 29 Spline; U-Bolt Style; For Use w/1350 U/Joint; 1.188 in. Cap Diameter; 3.625 in. Span; Forged Steel

Dana 60/44; For Use w/1350 U-Joint; U-Bolt Style; 3.219 in. Snap Ring Span; 1.062 in. Cap Diameter; Outside Snap Ring Dana Super 60; For Use w/1350 U-Joint; U-Bolt Style; 3.219 in. Snap Ring Span; 1.062 in. Cap Diameter; Outside Snap Ring~Dana Super 60; Pinion Yoke; For Use w/1310 U-Joint; U-Bolt Style; 3.219 in. Snap Ring Span; 1.062 in. Cap Diameter; Outside Snap Ring

Dana 60/Reverse; For Use w/1350 U-Joint; U-Bolt Style; 2.625 in. Snap Ring Span; 1.125 in. Cap Diameter; Inside Snap Ring Dana Super 60; For Use w/1350 U-Joint; U-Bolt Style; 2.625 in. Snap Ring Span; 1.125 in. Cap Diameter; Inside Snap Ring~Dana Super 60; Pinion Yoke; 29 Spline; For Use w/ 7290 U-Joint; Strap Style; 1.125 in. Cap Diameter; Inside Snap Rings

9.5 in. 14 Bolts Driveshaft at Rear Axle; For Use w/1350 U-Joints; Straps GM 9.5 in. & 8.6 in. Rear Pinion Yoke; 30 Spline; 1350 U-Joint size (1.188 in. Cap x 3.62 in. Span); Strap Style Yoke~GM 9.5 in.; 14 bolt cover; Rear Driveshaft at Rear Axle; For Use w/1350 U-Joints; Straps

10.5 in. 14 Bolt Driveshaft At Rear Axle; 1350; Strap Style GM 10.5 in. 14 Bolt Rear; Pinion Yoke; Strap Style; For 1350 Series U-Joint; 1.188 in. Cap Diameter; 3.625 in. Span~GM 10.5 in; 14 Bolt Cover; Rear Driveshaft At Rear Axle; 1350; Strap Style

Dana 60 Driveshaft at Front Axle or Rear Driveshaft at Rear Axle; 29 Spline; w/1350 U-Joint; U-Bolt Style Dana 60; Pinion Yoke; 29 Spline; U-Bolt Style; For Use w/1350 U/Joint; 1.188 in. Cap Diameter; 3.625 in. Span~Dana Super 60; Front Driveshaft at Front Axle or Rear Driveshaft at Rear Axle; 29 Spline; w/1350 U-Joint; U-Bolt Style

9.5 in. 14 Bolt Driveshaft at Rear Axle; For Use w/1350 U-Joint; Triple Lip Design GM 9.5 in. 14 bolt Rear; Pinion Yoke; Strap Style; For Use w/1350 U-Joint; 2.110 in. Hub Diameter~GM 9.5 in.; 14 bolt cover; Rear Driveshaft at Rear Axle; For Use w/1350 U-Joint; Triple Lip Design

7.25 in.; IFS; 26 Spline GM 7.2 in.; IFS; 26 Spline~GM 7.2 in.; IFS; Pinion Yoke; 26 Spline; Strap Style; For use w/ 1310 U-Joint;

10.5 in. 14 Bolt Driveshaft At Rear Axle; 1410; Strap Style GM 10.5 in. 14 Bolt Rear; Pinion Yoke; Strap Style; For 1410 Series U-Joint; 1.188 in. Cap Diameter; 4.188 in. Span~GM 10.5 in; 14 Bolt Cover; Rear Driveshaft At Rear Axle; 1410; Strap Style

Dana 60; For Use w/1350 U-Joint; U-Bolt Style; 4.188 in.; Snap Ring Span; 1.188 in. Cap Diameter; Outside Snap Ring Dana Super 60; For Use w/1350 U-Joint; U-Bolt Style; 4.18Snap Ring Span; 1.188 in. Cap Diameter; Outside Snap Ring~Dana Super 60; Pinion Yoke; 29 Spline; For Use w/ 1410 U-Joint; Strap Style; 4.188 in. U-Joint Span; 1.188 in. Cap Diameter;

Dana 60 Driveshaft at Front Axle or Rear Driveshaft at Rear Axle; For Use w/1410 U-Joint; Strap Style Dana 60 & Dana 70; Pinion Yoke Flange; 29 Spline; Round Flange; 5 in. Diameter; 8 x 4.25 in. BOLT PATTERN~Dana Super 60; Front Driveshaft at Front Axle or Rear Driveshaft at Rear Axle; For Use w/1410 U-Joint; Strap Style

Dana 60/Reverse; For Use w/1350 UJoint; UBolt Style; 4.188in. SnapRngSpan; 1.188in. Cap Dia.; [AWSL] Dana Super 60; For Use w/1350 UJoint; UBolt Style; 4.188in. SnapRngSpan; 1.188in. Cap Dia.; [AWSL]~Dana Super 60; Pinion Yoke; 29 Spline; For Use w/ 1410 U-Joint; U-Bolt Style; 4.188 in. U-Joint Span; 1.188 in. Cap Diameter;

For Use w/1350 U-Joint; U-Bolt Style; Billet Steel Dana Super 60; For Use w/1350 U-Joint; U-Bolt Style; Billet Steel~Dana Super 60; Pinion Yoke; 29 Spline; U-Bolt Style; For Use w/1350 U/Joint; 1.188 in. Cap Diameter; 3.625 in. Span; Billet Steel
