Chevrolet P30 Differential Pinion Seal Replacement

10.5 in. 14 Bolt GM 10.5 in.; 14 Bolt Cover; Rear

1.875 Shaft Diameter 3.160 Bore Diameter 3.165 Outside Diameter Seal 0.770 Width with 10.5 Ring Gear ; M.H.C.

2.598 Shaft Diameter 3.481 Bore Diameter 3.486 Outside Diameter Seal 0.438 Width ; H110 Axle

2.125 Shaft Diameter 3.623 Bore Diameter 3.628 Outside Diameter Seal 0.469 Width ; 12.00" Ring Gear w/o MHC

2.201 Shaft Diameter 3.519 Bore Diameter 3.523 Outside Diameter Seal 0.591 Width ; 10.50" 1st Design Ring Gear

w/Triple Lip GM 10.5 in; 14 Bolt Cover; w/Triple Lip

9.5" Ring Gear

4 Whl. Disc Brks. and M.H.C. FAG Global Number 413 2948 100 .770" Width

2.324 Shaft Diameter 3.541 Bore Diameter 3.546 Outside Diameter Seal 0.591 Width ; 10.5" Ring Gear 2nd Design

2.500 Shaft Diameter 4.035 Bore Diameter 4.040 Outside Diameter Seal 0.486 Width with 11.5 Ring Gear

with GMC H110 Differential Polyacrylate Type

1st Design, w/o Dana Axle 10.50" Ring Gear FAG Global Number 413 3147 100

9.75 in. Ring Gear

(10.5" R.G.)

with 13.46mm Width with Dana 70 Axle

Dana 80; Replacement; Non-Flanged Style Dana 80; Replacement; Non-Flanged Style

with 10.5 (in) Ring Gear with AAM Axle

2nd Design 10.50" Ring Gear FAG Global Number 413 3190 100

11.50" Ring Gear FAG Global Number 413 3251 100

Viton Type with 11 (mm) Ring Gear with Spicer 80 Axle

Differential Pinion Seal; 10.50 RING GEAR SAGINAW-AMERICAN AXLE; OUTER BEARING OIL) (2 PIECES PINION SEAL (TRIPLE-LIP). SEE PART NUMBER 26004811 FOR 1ST DESIGN.; 2nd Design; THIS SEAL WILL ONLY WORK With 2 PIECES SEAL DESIGN, WHICH MATES With SEAL PRESSED

Replaces OE Part Number(s) 12387291 with .609in Width with Dana 80 Axle
