Dodge B250 Wheel Seal Replacement

8.25" Ring Gear

5 Stud Hub 3,300 lb. Axle

9.25" Ring Gear Heavy Duty Axle

1.618 Shaft Diameter 2.575 Bore Diameter 2.579 Outside Diameter Seal 0.500 Width with 8.375 Ring Gear

1.938 Shaft Diameter 2.621 Bore Diameter 2.626 Outside Diameter Seal 0.570 Width ; 3000 lb., 3300 lb. Axles w/ 5 Stud Hub

In Brake Drum - w/ 12" X 2.5" Rear Brakes

w/ Light Duty 9.25" Chrysler Axle (5 Lug)

with 5 Stud Hub with 3,300 (lb) Axle(s)

3,300 lb. Axle - 5 Stud

2.500 Shaft Diameter 3.301 Bore Diameter 3.306 Outside Diameter Seal 0.453 Width ; Spicer 60, 70 Axles w/ 12" X 2.5" Brks.

8.25 in., 8.38 in. Ring Gear

w/ Heavy Duty 9.25" Chrysler Axle (8 Lug)

w/ Light Duty 9.25" Chrysler Axle (5 Lug)

Spicer 60,70 Axles 12" x 2.5" Brake Shoe FAG Global Number 413 3234 100

2.048 Shaft Diameter 2.727 Bore Diameter 2.732 Outside Diameter Seal 0.570 Width ; 3300 lb., 3600 lb. Axles, 8 Stud Hub

In Brake Drum - w/ 12" X 2.5" Rear Brakes

Except 4000 LB Axle

In Brake Drum - w/ 12" X 3" Rear Brakes Except 9000 LB GVW

3.154 in. Bore Diameter 0.375 in. Width 2.281 in. Shaft Diameter 3.159 in. Outside Diameter Seal ; 3800 lb., 4000 lb. Axles w/ 8 Stud Hub

w/o 4000 lb. Axle 5,8 Stud Hub Assembly FAG Global Number 413 3072 100

2.875 Shaft Diameter 3.876 Bore Diameter 3.881 Outside Diameter Seal 0.610 Width ; Spicer 60, 70 Axles w/ 12" X 3" Brks., 9,000 lb GVW

w/ Light Duty 9.25" Chrysler Axle (5 Lug)

with 8 Stud Hub with 3,600 (lb) Axle(s)

3,600 lb. Axle - 8 Stud

with 9.25 (in) Ring Gear with Heavy Duty Axle

Spicer 60,70 Axles,9000 lb. G.V.W. 12" x 3" Brake Shoe FAG Global Number 413 3311 100 w/Flange

8 Stud Hub Assembly 4,000lb Axle Weight FAG Global Number 413 3183 100

3,800, 4,000 lb. Axle - 8 Stud

9.25 in. Ring Gear - Heavy Duty Axle

3.000 Shaft Diameter 4.249 Bore Diameter 4.254 Outside Diameter Seal 0.438 Width ; Spicer 60, 70 Axles w/ 12" X 3" Brks. w/o 9,000 lb GVW

Except 4000 LB Axle

Spicer 60,70 Axles, w/o 9000 lb. G.V.W. 12" x 3" Brake Shoe FAG Global Number 413 3335 100
