Dodge B300 Wheel Bearing Replacement

8 Stud Hub 3,800 lb. Axle

with 3300lb Gross Vehicle Weight (GVW) with 3000lb Gross Vehicle Weight (GVW) with 5 Stud Hub

with 3300lb Gross Vehicle Weight (GVW) with 3000lb Gross Vehicle Weight (GVW) with 5 Stud Hub

9.25" Ring Gear FAG Global Number FC67148.5 .830" Wide Brg.

with 0.8656 in. Bearing Inside Diameter with 1.8110 in. Outside Diameter Bearing(s) 1.8110 in. Width 0.6550 in. Cone Length 0.4750 in. Cup Length ; 3000 lb., 3300 lb. Axles w/ 5 Stud Hub

with 1.3775 in. Bearing Inside Diameter with 2.3612 in. Outside Diameter Bearing(s) 2.3612 in. Width 0.6600 in. Cone Length 0.4700 in. Cup Length ; 3000 lb., 3300 lb. Axles w/ 5 Stud Hub

with 3600lb Gross Vehicle Weight (GVW) with 8 Stud Hub

0.6693 in. Cone Length 0.5315 in. Cup Length with 1.496 in. Bearing Inside Diameter with 2.480 in. Outside Diameter Bearing(s) 0.669 in. Width ; w/3600 lb. Axle, 8 Stud Hub

with 4000lb Gross Vehicle Weight (GVW) with 8 Stud Hub

4,000 LB Axle

Replacement Bearing 9.25" Ring Gear

with 4000lb Gross Vehicle Weight (GVW) with 8 Stud Hub

Advantage; 8 Stud; 3800lb Axle

with 8 Stud Hub with 3,600 (lb) Axle(s) Taper Bearing Set Includes Cup and Cone

Spicer Axle 70 12" X 3" Brakes 9,000 lb. GVW

with Dana 60 Axle with 12in x 2.5in Brakes

with 8 Stud Hub with 4,500 (lb) Axle(s)

with 9.25in Ring Gear; Standard Replacement Bearing

0.7800 in. Cone Length 0.5800 in. Cup Length with 1.625 in. Bearing Inside Diameter with 2.891 in. Outside Diameter Bearing(s) 0.770 in. Width ; 3800 lb., 4000 lb. Axles w/ 8 Stud Hub

Axle Repair Bearing 9.25" Ring Gear

with 8 Stud Hub with 3,800 (lb) Axle(s) Taper Bearing Set Includes Cup and Cone

with 1.7812 in. Bearing Inside Diameter with 3.0625 in. Outside Diameter Bearing(s) 3.0625 in. Width 0.7812 in. Cone Length 0.5937 in. Cup Length ; w/3800 lb., 4000 lb. Axles, 8 Stud Hub

with 2.0000 in. Bearing Inside Diameter with 3.2500 in. Outside Diameter Bearing(s) 3.2500 in. Width 0.8750 in. Cone Length 0.6500 in. Cup Length ; Spicer 70 Axle w/ 12" X 3" Brks. w/Spicer 60 Axle, Dual Rr. Whls.

4500 LB Axle

4,500 lb. Axle

Spicer Axle 70 12" X 3" Brakes Exc. 9,000 lb. GVW

Standard Design with 9.25 (in) Ring Gear

with 12 (in) x 3 (in) Brakes with 9,000 (lb) Gross Vehicle Weight (GVW) with Spicer 70 Axle

9.25 in. Ring Gear

Rear Bearing Kit with Heavy Duty Axle with 9.25in Ring Gear ; Repair Bearing With Seal

Spicer 60 - HD - 70 Axle - 12 in. x 3 in. Brakes 9000 lb. GVW

Spicer 60 and 70 Axles 9,000 lb. G.V.W. 12" x 3" Brake Shoe FAG Global Number 401041

with 2.2500 in. Bearing Inside Diameter with 3.8437 in. Outside Diameter Bearing(s) 3.8437 in. Width ; Spicer 60, 70 Axles w/ 12" X 3" Brks., 9",000 lb GVW

Spicer 60 Axle - 12 in. x 2.5 in. Brakes

with 9.25 (in) Ring Gear with Axle Repair Bearing Assembly

Except 9,000 (lb) GVW with 12 (in) x 3 (in) Brakes with Spicer 70 Axle

with 8.75 Ring Gear with 1.562 in. Bearing Inside Diameter with 2.875 in. Outside Diameter Bearing(s) 1.010 in. Width

Spicer 60 Axle - 12 in. x 2.5 in. Brakes

Spicer 60 - HD - 70 Axle - 12 in. x 3 in. Brakes Non 9,000 lb. GVW

Spicer 60 - HD - 70 Axle - 12 in. x 3 in. Brakes Non 9,000 lb. GVW

Spicer 70 axle 12" x 3" Brake Shoe FAG Global Number 201063

with 2.250 in. Bearing Inside Diameter with 4.125 in. Outside Diameter Bearing(s) 1.187 in. Width ; Spicer 70 Axle w/ 12" X 3" Brks. w/Spicer 60 Axle, Dual Rr. Whls.
