Dodge Charger Wheel Seal Replacement

Spicer Axle 60

8.25" Ring Gear

11" Brakes

10" Brakes

1.399 Shaft Diameter 2.292 Bore Diameter 2.296 Outside Diameter Seal 0.469 Width with 7.25 Ring Gear

1.618 Shaft Diameter 2.575 Bore Diameter 2.579 Outside Diameter Seal 0.500 Width with 8.25 , 9.25 Ring Gear

1.938 Shaft Diameter 2.621 Bore Diameter 2.626 Outside Diameter Seal 0.570 Width

with 8.25 (in) Ring Gear

7.25" Ring Gear FAG Global Number 413 2468 100 1.399" Shaft

8.25 in. Ring Gear

8.25 in., 9.25 in. Ring Gear

FAG Global Number 413 2995 100

8.25",9.25" Ring Gear FAG Global Number 413 2698 100 .70" Wide Brg. .830" Wide Brg. 1.024" Wide Brg.

1.673 Shaft Diameter 2.162 Bore Diameter 2.168 Outside Diameter Seal 0.290 Width

1.500 Shaft Diameter 2.502 Bore Diameter 0.313 Width

FAG Global Number 413 2726 100

FAG Global Number 413 2071 100

FAG Global Number 413 3149 100

9.75" Ring Gear FAG Global Number 413 2577 100 2.506" O.D.

FAG Global Number 413 2542 100

1.730 Shaft Diameter 2.336 Bore Diameter 2.340 Outside Diameter Seal 0.250 Width ; 10" Brks.

1.552 Shaft Diameter 2.686 Bore Diameter 2.690 Outside Diameter Seal 0.500 Width with 8.75 , 9.25 Ring Gear

1.730 Shaft Diameter 2.336 Bore Diameter 2.340 Outside Diameter Seal 0.470 Width ; 11" Brks.

with 10 (in) Brakes

1.893 Shaft Diameter 2.434 Bore Diameter 2.438 Outside Diameter Seal 0.250 Width with 9.75 Ring Gear

10" Brake Shoe FAG Global Number 413 2765 100

1.328 Shaft Diameter 2.227 Bore Diameter 2.231 Outside Diameter Seal 0.313 Width with 7.25 Ring Gear ; w/o 10" Brks.

11" Brks. FAG Global Number 413 2763 100

8.75",9.75" Ring Gear FAG Global Number 413 2597 100

10 in. Brakes

8.75",9.75" Ring Gear FAG Global Number 413 2964 100

with 7.25 (in) Ring Gear
