Dodge Dart Wheel Seal Replacement

9" Brakes

8.75" Ring Gear

7.25" Ring Gear 10" Brakes

11" Brakes

8.25" Ring Gear

7.25" Ring Gear 9" Brakes

1.399 Shaft Diameter 2.292 Bore Diameter 2.296 Outside Diameter Seal 0.469 Width with 7.25 Ring Gear ; 10" Brks.

1.938 Shaft Diameter 2.502 Bore Diameter 2.506 Outside Diameter Seal 0.281 Width

1.618 Shaft Diameter 2.575 Bore Diameter 2.579 Outside Diameter Seal 0.500 Width with 8.25 Ring Gear

1.938 Shaft Diameter 2.621 Bore Diameter 2.626 Outside Diameter Seal 0.570 Width

with 10 (in) Brakes with 7.25 (in) Ring Gear

10" Brake Shoe 7.25" Ring Gear FAG Global Number 413 2468 100 1.399" Shaft

with Drum Brakes

FAG Global Number 413 2977 100

7.25 in. Ring Gear - 10 in. Brakes

with Disc Brakes

8.25 in. Ring Gear

8.25" Ring Gear FAG Global Number 413 2698 100 .70" Wide Brg. .830" Wide Brg. 1.024" Wide Brg.

1.500 Shaft Diameter 1.989 Bore Diameter 1.993 Outside Diameter Seal 0.250 Width ; 9" Brks.

with 9 (in) Brakes

9" Brake Shoe FAG Global Number 413 2542 100

with Posi-Traction

1.730 Shaft Diameter 2.336 Bore Diameter 2.340 Outside Diameter Seal 0.250 Width ; 10" Brks.

9 in. Brakes

1.375 Shaft Diameter 2.686 Bore Diameter 2.690 Outside Diameter Seal 0.500 Width

1.552 Shaft Diameter 2.686 Bore Diameter 2.690 Outside Diameter Seal 0.500 Width with 8.75 Ring Gear

1.730 Shaft Diameter 2.336 Bore Diameter 2.340 Outside Diameter Seal 0.470 Width ; 11" Brks.

1.893 Shaft Diameter 2.434 Bore Diameter 2.438 Outside Diameter Seal 0.250 Width with 8.75 Ring Gear

10" Brake Shoe FAG Global Number 413 2765 100

1.328 Shaft Diameter 2.227 Bore Diameter 2.231 Outside Diameter Seal 0.313 Width with 7.25 Ring Gear ; 9" Brks.

11" Brks. FAG Global Number 413 2763 100

8.75" Ring Gear FAG Global Number 413 2597 100

Except Posi-Trac

FAG Global Number 413 2440 100

8.75" Ring Gear FAG Global Number 413 2964 100

with 9 (in) Brakes with 7.25 (in) Ring Gear

7.25" Ring Gear FAG Global Number 413 2372 100
