Off-Idle to 5500rpm Adv. Dur. at 0.050 Int/Exh. 204/204 Deg. Lift at Valve Int/Exh. 0.420 in. Lobe Seps 110 Deg. Intake Center Line 106 Deg. Engines Transplanted Into Uncontrolled/Pre-Pollution Vehicle Not For 1985 And Later Engines w/Roller Lifters~ Idle Vacuum at 1000 RPM - 16 inch~ Designed For The Engine Swap Market~ Not Legal For Use On Pollution Controlled Vehicles~ Produces 305 ft.-lbs When Matched w/2176 Intake and Stock Heads
Class 1, Excellent Low End Torque And Horsepower Good Idle And Daily Usage Use With VS-1120 Valve Spring. Installed Height 1.65 Inches Not California Compliant
Class 1, Excellent Low End Torque And Horsepower Good Idle And Daily Usage Use With VS-1120 Valve Spring. Installed Height 1.65 Inches Not California Compliant
Off-Idle to 5500rpm Adv. Dur. at 0.050 Int/Exh 204/214 Deg. Lift at Valve Int/Exh 0.420/0.442 in. Lobe Seps 112 Deg Intake Center Line 107 Deg Engines Transplanted Into Uncontrolled/Pre-Pollution Vehicle Idle Vacuum at 1000 RPM - 14 inch~ Designed For The Engine Swap Market~ Not Legal For Use On Pollution Controlled Vehicles~ Produces 427 ft.-lbs. When Matched w/2191 Intake and Stock Heads~ Camshaft Utilizes One Bolt Configuration
Hyd. 1500-6500rpm Adv. Dur. at 0.050 Int/Exh 234/244 Deg. Lift at Valve Int/Exh 0.488/0.510 in. Lobe Seps 112 Deg. Intake Center Line 107 Deg. Engines Transplanted Into Uncontrolled/Pre-Pollution Vehicle Not For 1985 And Later Engines w/Roller Lifters~ Adjustable Pushrods Or Rocker Arms Required~ Idle Vacuum at 1000 RPM - 10 inch~ Designed For The Engine Swap Market~ Not Legal For Use On Pollution Controlled Vehicles~ Produces 417hp and 397 ft.-lbs. When Matched w/60779 Heads
Hyd.. 1500-6500rpm Adv. Dur. at 0.050 Int/Exh 238/246 Deg. Lift at Valve Int/Est 0.480/0.495 in. Lobe Seps 110 Deg. Intake Center Line 105 Deg. Engines Transplanted Into Uncontrolled/Pre-Pollution Vehicle Adjustable Pushrods Or Rocker Arms Required~ Idle Vacuum at 1000 RPM - 10 inch~ Designed For The Engine Swap Market~ Not Legal For Use On Pollution Controlled Vehicles~ Produces 469hp and 515 ft.-lbs. When Matched w/7193 Intake and 60929 Heads~ Camshaft Utilizes One Bolt Configuration
Browse our selection of quality engine camshaft and lifter kit parts designed specifically for your Dodge Magnum. We carry options across multiple trim levels, body styles, and engine configurations to ensure a perfect fit.
Base · XE
Coupe
V8 5.2L · V8 5.9L · V8 6.6L
Automatic · Manual
