Direct Replacement
4 Hole Aftermarket Billet Aluminum Spacer; For PRW FluidGel(TM) Dampers; Black Anodized
4 Bolt Hub; W/ 28 oz Weight Part Type: Solid Outer Diameter: 6.40 in ATP Number: 102017 ATP Availability: Available to Order Pioneer Number: DA-3513 Pioneer Availability: Available to Order Pioneer Supersession: Replaces DA-7003
Description: 4 Bolt Hub; W/ 28 oz Weight Part Type: Solid Outer Diameter: 6.40 in Supersession: Replaces DA-7003
For Vehicles W/ Weighted Spacer Behind Balancer Part Type: Solid Outer Diameter: 6.50 in ATP Number: 102011 ATP Availability: Available to Order Pioneer Number: DA-4601 Pioneer Availability: Available to Order
Description: For Vehicles W/ Weighted Spacer Behind Balancer Part Type: Solid Outer Diameter: 6.50 in
4 Bolt Hub; W/ 50 oz Weight Part Type: Solid Outer Diameter: 6.41 in ATP Number: 102014 ATP Availability: Available to Order ATP Supersession: Replaces 102012 Pioneer Number: DA-3021 Pioneer Availability: Available to Order Pioneer Supersession: Replaces DA-3023
Description: 4 Bolt Hub; W/ 50 oz Weight Part Type: Solid Outer Diameter: 6.41 in Supersession: Replaces DA-3023
Direct Replacement
3 Bolts Hub Part Type: Solid Outer Diameter: 6.50 in ATP Number: 102008 ATP Availability: Available to Order Pioneer Number: DA-289 Pioneer Availability: Available to Order
Description: 3 Bolts Hub Part Type: Solid Outer Diameter: 6.50 in
Description: 4 Bolt Hub; W/ 28 oz Weight Part Type: Solid Outer Diameter: 6.54 in Supersession: Replaces DA-7007
Direct Replacement
3 bolt w/counterweight & raised pulley
Direct Replacement
Description: 4 Bolt Hub; W/ 28 oz Weight Part Type: Solid Outer Diameter: 6.51 in
Direct Replacement
Supersession: Renumbered from DA-3512-HD
Direct Replacement
6.40 in. OD; 28 oz. External Balance; Removable C/Weight; Black
Street Version
6.40 in. OD; 50 oz. External Balance; Removable C/Weight; Black
Description: 3-3/4 In Hub Height Part Type: Solid Outer Diameter: 6.062 in
Condition: Excellent (A)
Mileage: 209,000 miles
6.50 in. OD; 0 Balance; Black
3.75 Hub Height
SFI Spec 18.1; Steel/Elastomer; External Balance; 6.40 in. OD; Removable C/Weight; 50 Oz.; Black
Dual Groove Pulley
6.54 in. OD; 50 Oz.; Removable Hub; External Balance; Black
SFI Spec 18.1; Steel/Elastomer; External Balance; 6.40 in. OD; Removable C/Weight; 28 Oz.; Black
6.40 in. OD; 28 oz. External Balance; Lightweight; Black
6.40 in. OD; 50 Oz.; Lightweight; Black
7.25 in. OD; Neutral Balance; 4 Bolt Pulley; Keyway Matching May Be Required For OEM/Aftermarket Cranks; Black
6.40 in. OD; Neutral Balance; Removable C/Weight; Standard Weight; Black
6.54 in. OD; 28 Oz; Removable Hub; External Balance; Pulley Spacers May Be Required 1975-Up Engines; Black
6.54 in. OD; Zero Balance For Aftermarket Cranks; Internal Balance; Black
Bore Dia. Min/Max: 1.374 / 1.375 Degree Marking Range: 2 degree increments, 50 BTDC to 10 ATDC Degree Markings: Yes Engine Balance: External (28 oz) Finish: No Finish Keyway: Single Length: 3.33 Material: Steel Mounting Hardware Incl.: No O.D.: 6-1/4" (6.25) Safety Rating: Non SFI Approval WT. in lbs.()=Rotating weight: 11.0 (7.8 Rwt) 4 bolt standard Ford pulley bolt pattern. Externally balanced-28oz. Not recommended for 302HO Pulley spacer PN 717656 may be required Recommend painting with high temperature engine paint to prevent rust.
SFI Spec 18.1; Steel/Elastomer; Zero Internal Balance; 6.50 in. OD; Black
Description: 4 Bolt Hub; W/ 28 oz Weight Part Type: Solid Outer Diameter: 6.50 in w/28oz. Counter Weight Hubs Street Performance Balancer
Bore Dia. Min/Max: 1.374 / 1.375 Degree Marking Range: 2 degree increments, 50 BTDC to 10 ATDC Degree Markings: Yes Engine Balance: Internal Finish: Black Zinc Keyway: Single Length: 3.34 Material: Steel Mounting Hardware Incl.: No O.D.: 6-5/8" (6.625) Pulley Bolt Pattern: Pulley spacers may be required on some 1975-later engines. Custom pulleys may be Safety Rating: SFI 18.1 WT. in lbs.()=Rotating weight: 11.1 (7.4 Rwt) 4 bolt standard Ford pulley bolt pattern. Custom pulleys may be required Internally balanced. Replaces 28oz externally balanced.
Bore Dia. Min/Max: 1.374 / 1.375 Degree Marking Range: 2 degree increments, 50 BTDC to 10 ATDC Degree Markings: Yes Engine Balance: External (28 oz) Finish: Black Zinc Keyway: Single Length: 3.34 Material: Steel Mounting Hardware Incl.: No O.D.: 6-5/8" (6.625) Safety Rating: SFI 18.1 WT. in lbs.()=Rotating weight: 12.5 (8.3 Rwt) 4 bolt standard Ford pulley bolt pattern. Externally balanced-28oz. Recommend painting with high temperature engine paint to prevent rust.
Description: 3 Bolts; W/ Counterweight & Raised Pulley Part Type: Solid Outer Diameter: 6.50 in
Bore Dia. Min/Max: 1.374 / 1.375 Degree Marking Range: 2 degree increments, 50 BTDC to 10 ATDC Degree Markings: Yes Engine Balance: Internal Finish: Black Zinc Keyway: Single Length: 3.95 Material: Steel Mounting Hardware Incl.: No O.D.: 6-5/8" (6.625) Safety Rating: SFI 18.1 WT. in lbs.()=Rotating weight: 11.8 (7.9 Rwt) Internally balanced. Replaces 34oz. externally balanced.
Description: 3 Bolt Hub; W/ Counterweight & Counter Sunk Pulley Part Type: Solid Outer Diameter: 6.5 in
Bore Dia. Min/Max: 1.374 / 1.375 Degree Marking Range: 2 degree increments, 50 BTDC to 10 ATDC Degree Markings: Yes Engine Balance: External (50 oz) imbalance, 34 oz on damper and 16 oz on flywheel Finish: Black Zinc Keyway: Single Length: 4.12 Material: Steel Mounting Hardware Incl.: No O.D.: 6-9/16" (6.55) Pulley Bolt Pattern: 93-95 stock pulleys will not fit Fluidampr Safety Rating: SFI 18.1 WT. in lbs.()=Rotating weight: 13.7 (11.2 Rwt) 34 OZ EXT.
Description: 4 Bolts Part Type: Solid Outer Diameter: 6.62 in
3 Bolts; W/ Counterweight & Raised Pulley Part Type: Solid Outer Diameter: 6.50 in ATP Number: 102029 ATP Availability: Discontinued Pioneer Number: 872008 Pioneer Availability: Available to Order ATP: Discontinuation / supersession date: 2020-11-24 ATP: Obsolete On: 2022-11-24 ATP: LifeCycle Change Log: Available to Order -> Discontinued ATP: LifeCycle Ticket Log: JNP-18368
Description: Neutral Balance Part Type: Solid Outer Diameter: 5.79 in
Bore Dia. Min/Max: 1.374 / 1.375 Degree Marking Range: 50 degree BTDC to 10 degree ATDC. Additional timing/degree marks at 90, 180 and Degree Markings: Yes Engine Balance: Internal Finish: Black Zinc Keyway: Single Length: 2.385 Material: Steel Mounting Hardware Incl.: No O.D.: 7-1/4" (7.250) Safety Rating: SFI 18.1 WT. in lbs.()=Rotating weight: 12.2 (8.2 Rwt) 385-SERIES BIG BLOCK
Description: 4 Bolt Hub; W/ 28 oz Weight Part Type: Solid Outer Diameter: 6.36 in
Description: W/ 50 oz Weight Part Type: Solid Outer Diameter: 6.36 in
Description: Hub Weighted Part Type: Solid Outer Diameter: 6.5 in w/28oz. Counter Weight Hub & Raised Pulley Location Performance Race (SFI) Harmonic Balancer
Browse our selection of quality engine harmonic balancer parts designed specifically for your Ford LTD. We carry options across multiple trim levels, body styles, and engine configurations to ensure a perfect fit.
Base · Brougham · Country Squire · Country Squire LX · Crown Victoria · Crown Victoria LX · LX Brougham · Landau · S
Convertible · Fastback · Hardtop · Sedan · Wagon
L4 2.3L · L6 3.3L · L6 3.9L · V6 3.8L · V8 4.2L · V8 4.7L · V8 5.0L · V8 5.8L · V8 6.4L · V8 6.6L · V8 7.0L · V8 7.5L
Automatic · Manual · U/K
