GMC C1500 Drive Shaft Center Support Bearing Replacement

Cushion Only

with 1.50in Mounting with 38mm Mounting Bearing Not Included

with 1.1811in & 30mm Inside Diameter Bearing(s) 3.50in Center Line Of Bearing To Mounting Face 89mm Center Line Of Bearing To Mounting Face with 1.50in Mounting with 38mm Mounting with Spicer Series 1280, 1310 accepted Slip Yoke Style Complete Assembly

Bearing not Included Contains Rubber Piece only

with 1.3780in & 35mm Inside Diameter Bearing(s) 2.28in Center Line Of Bearing To Mounting Face 58mm Center Line Of Bearing To Mounting Face with 168mm Mounting with 6.62in Mounting with Spicer Series 1280, 1310, 1350, 1410 accepted Slip Yoke Style

with 1.5750in & 40mm Inside Diameter Bearing(s) 2.48in Center Line Of Bearing To Mounting Face 63mm Center Line Of Bearing To Mounting Face with U-Shaped Bracket with 168mm Mounting with 6.62in Mounting with Dust Shields with Spicer Series 1410, 1480 accepted

without Mounting Studs with 1.5750in & 40mm Inside Diameter Bearing(s) 2.28in Center Line Of Bearing To Mounting Face 58mm Center Line Of Bearing To Mounting Face with Mounting Holes with 168mm Mounting with 6.62in Mounting with Cleveland O Shaft

Spicer 1280, 1310, 1330, 1410 Series 1.3780" Bearing I.D. Slip Yoke Style Without slingers

Spicer 1410 Series 1.5748" Bearing I.D.

Spicer 1280, 1310, 1330, 1410 Series 1.3780" Bearing I.D. Slip Yoke Style Optional with slingers

0.630 in. Width with 1.181 in. Bearing Inside Diameter with 3.851 in. Outside Diameter Bearing(s) ; Spicer 1280, 1310 U-joint Series w/ 30mm End Yoke

Spicer 1280, 1310, 1330 and 1410 U-joint Series w/35mm End Yoke FAG Global Number 713 0152 100

Slip Yoke Style with 1.378 (in) Bearing Inside Diameter with 35 (mm) Bearing Inside Diameter with Spicer 1280,1310,1330,1410 U-Joint(s)

Spicer 1280,1310 U-joint Series,w/30mm End Yoke FAG Global Number 713 0149 100 Bearing Lenght 35,1280-1310 Series U-Joints

U Bracket w/o Mounting Block and 1.575" ID; w/Studs In Bracket FAG Global Number 713 0171 100

1.850 in. Width with 1.574 in. Bearing Inside Diameter with 4.819 in. Outside Diameter Bearing(s) 6.616 in. Bolt Hole Centers ; w/o Studs In Bracket

1.850 in. Width with 1.574 in. Bearing Inside Diameter with 7.756 in. Outside Diameter Bearing(s) ; U Bracket w/o Mounting Block, 1.575" ID w/ Studs In Bracket

Kit

1.575" Bearing. I.D.;W/O Studs in Bracket FAG Global Number 713 0155 100

1.889 in. Width with 1.377 in. Bearing Inside Diameter with 4.299 in. Outside Diameter Bearing(s) 6.614 in. Bolt Hole Centers ; Flat Bracket W/ 1.378" ID w/ Studs In Bracket

w/o Pressfit Studs FAG Global Number 713 0156 100 1.375" I.D.

Kit

1.850 in. Width with 1.575 in. Bearing Inside Diameter with 4.687 in. Outside Diameter Bearing(s) ; U Bracket w/ Mounting Block, 1.575" ID w/ Studs In Bracket

Flat Bracket W/1.378" ID; w/ Studs In Bracket FAG Global Number 713 0169 100 1.378" I.D. Flat Brkt. w/ 1.378" I.D.

U Bracket w/ Mounting Block and 1.575 " ID; w/ Studs In Bracket FAG Global Number 713 0167 100
