GMC Jimmy Differential Pinion Seal Replacement

1.938 Shaft Diameter 2.762 Bore Diameter 2.766 Outside Diameter Seal 0.500 Width with 8.50, 8.625 Ring Gear 1st Design

1.732 Shaft Diameter 2.653 Bore Diameter 2.658 Outside Diameter Seal 0.547 Width with 7.5 Ring Gear

w/ 8.50" or 8.625" Ring Gear - w/o Triple Lip

1st Design with 8.5 (in) Ring Gear 0.5 (in) Width with AAM Axle 2.766 (in) Outside Diameter

2nd Design with 7.625 (in) Ring Gear 0.375 (in) Width with AAM Axle 2.657 (in) Outside Diameter

2.125 Shaft Diameter 2.763 Bore Diameter 2.767 Outside Diameter Seal 0.500 Width with 8.50, 8.625 Ring Gear 2nd Design

7.50" Ring Gear FAG Global Number 413 2796 100

8.50" Ring Gear FAG Global Number 413 2983 100 1.938" Shaft

w/ 8.50" or 8.625" Ring Gear - w/o Triple Lip

8.5 in. Ring Gear

with 8.625 (in) Ring Gear with AAM Axle

1.524 Shaft Diameter 2.656 Bore Diameter 2.660 Outside Diameter Seal 0.607 Width with 7.50, 7.625 Ring Gear

1.552 Shaft Diameter 3.160 Bore Diameter 3.165 Outside Diameter Seal 0.665 Width ; Dana 44 Axle

with 8.875 (in) Ring Gear with GMC Axle

8.50",8.625" Ring Gear FAG Global Number 413 3119 100

1.520 Shaft Diameter 2.656 Bore Diameter 2.660 Outside Diameter Seal 0.425 Width with 7.25 Ring Gear

7.5 in., 7.63 in. Ring Gear 1.6 in.

Differential Pinion Seal; 7.625 RING GEAR SAGINAW-AMERICAN; 2nd Design; With 2 PIECE PINION SEAL (TRIPLE LIP)) (FOR 1st DESIGN SEE 26026792

8.88 in. Ring Gear

9.50" Ring Gear F44 Heavy Duty Chassis 1st Design FAG Global Number 413 2987 100

8.5", 8.625" Ring Gear

with 7.625 (in) Ring Gear with AAM Axle

w/ 8.50" or 8.625" Ring Gear - w/o Triple Lip

with 7.25 (in) Ring Gear with AAM Axle Independent Front Suspension

1.940 Shaft Diameter 2.900 Bore Diameter 2.910 Outside Diameter Seal 0.421 Width with 8.25 Ring Gear

w/ 8.50" or 8.625" Ring Gear

with 7.25 (in) Ring Gear with AAM Axle Independent Front Suspension

w/ Spicer/Dana 44 Axle FAG Global Number 413 2633 100

Nitrile with 8.5 (in) Ring Gear with Spicer 44-8F Axle

7.25" Ring Gear FAG Global Number 413 2585 100

7.50",7.625" Ring Gear FAG Global Number 413 2588 100 1.500" Shaft

9.5" Ring Gear 1st Design

7.5 in., 7.63 in. Ring Gear 1.5 in. I.D.

with 9.75 (in) Ring Gear with Spicer 60-35 Axle

Dana/Spicer 60 Series Axle

8.13 in. Ring Gear

w/ 8.50" or 8.625" Ring Gear

8.25" Ring Gear FAG Global Number 413 2994 100

Spicer

8.25 in. Ring Gear

Non Spicer Axle

9.5" Ring Gear 2nd Design

Excluding 8.50" & 8.625" Ring Gears

9.50" Ring Gear FAG Global Number 413 3085 100

Viton Type with 8.5 (in) Ring Gear with Spicer 44-8F Axle
