GMC Jimmy Electric Fuel Pump Replacement

Recommend to replace Wiring Harness FW900 Includes Tank Seal Strainer required to validate the warranty: F123S

12 volt 2.5 to 4.5 pounds of pressure Requires 3" x 5" Mounting Area

Exc. Kuwait, Saudi Arabia, Gulf States Export Models Recommend to replace Wiring Harness FW900 Includes Tank Seal Strainer required to validate the warranty: F123S

Universal 12 Volt 5 to 9 pounds of pressure. Requires 3" x 5" Mounting Area

w/ CAE or CEH on Wiring Harness Tag

with digital dash; Platinum Pro Part New Strainer Required For Warranty

1 locking tab on internal pump connector. 38mm body with brass return jet on pump body and black jet hose.

Platinum Pro Part New Strainer Required For Warranty

2 locking tabs on internal pump connector. 4 doormodel. 52mm large diameter body.

(Universal Inline) (12 Volt 4 to 6 PSI) Requires 3" x 6" Mounting Area

For Use w/Carburetor; Domestic; 4-7 psi; 35 gph;CARB E.O. D-550-34

Electric Replacement for Mechanical When converting from OE mechanical pump to inline electric system an additional inline fuel pressure regulator may be required to maintain proper line pressure

Failure To Install A New Fuel Strainer (Where Applicable) Will Void Warranty

High-Pressure Single Tank 57 gph at 43 PSI

340 LPH E85 Compatible; Pump Center Offset; Hardware Kit;50 State Legal/California Emissions Compliant

67 GPH 255 Liter/Hr.
