Honda Ridgeline Tire Pressure Monitoring System (TPMS) Sensor Serv Replacement

with steel wheels oe style ; w/o Valve 25 Per Box No programming required. Install sensor and follow the OEM factory relearn procedure.

with steel wheels oe style ; w/o Valve 4 Per Box No programming required. Install sensor and follow the OEM factory relearn procedure.

oe style; w/o Valve w/ Alloy Wheels 25 Per Box No programming required. Install sensor and follow the OEM factory relearn procedure.

oe style; w/o Valve w/ Alloy Wheels 4 Per Box No programming required. Install sensor and follow the OEM factory relearn procedure.

Mounting Method: Clamp-In components Torque: Nut Torque = 71in-lbs, 8Nm; Valve core torque = 3.5 in-lbs, 0.4Nm Max Speed Rating: 130 Max Pressure Rating: 102 Without Mounting Hardware Valve Not Included Valve Cap Not Included Valve Stem Not Included Washer Not Included Quantity Included: 1

Metal Clamp-in Stem; 315 MHz; Multi-application Sensor

433.90 MHz Sensor

Services factory equipped TPMS Sensors

Mounting Method: Clamp-in valve assembly components Torque: Nut torque = 35in-lbs, 4Nm; Valve core torque = 3.5 in-lbs, 0.4Nm Max Speed Rating: 130 Max Pressure Rating: 102 Without Mounting Hardware Valve Included Valve Cap Not Included Valve Stem Not Included Valve Type Short Washer Not Included Quantity Included: 1

Mounting Method: Clamp-In components Torque: Nut Torque = 71in-lbs, 8Nm; Valve core torque = 3.5 in-lbs, 0.4Nm Max Speed Rating: 130 Max Pressure Rating: 102 Without Mounting Hardware Valve Not Included Valve Cap Not Included Valve Stem Not Included Washer Not Included Quantity Included: 1

315 MHz Sensor with Valve Stem 1.750in Valve Stem

315 MHz Sensor with Valve Stem 2.250in Valve Stem

Mounting Method: Clamp-in valve assembly components Torque: 35in-lbs, 4N.m Max Speed Rating: 130 Max Pressure Rating: 102 Without Mounting Hardware Valve Included Valve Cap Not Included Valve Stem Not Included Valve Type Long Washer Not Included Quantity Included: 1
