Jeep Liberty Differential Pinion Seal Replacement

Dana 30/44; Super;

Chrysler 8.25 in.

Replaces OE Part Number(s) 83504946 with Dana 35 Axle

1.732 Shaft Diameter 2.614 Bore Diameter 2.621 Outside Diameter Seal 0.570 Width ; 8.25" Axle

1.842 Shaft Diameter 2.748 Bore Diameter 2.751 Outside Diameter Seal 0.426 Width ; Spicer 35 Axle

1.873 Shaft Diameter 3.057 Bore Diameter 3.062 Outside Diameter Seal 0.492 Width

1.827 Shaft Diameter 3.068 Bore Diameter 3.063 Outside Diameter Seal 0.475 Width

8.25" Ring Gear FAG Global Number 413 2788 100

with 7.59 (in) Ring Gear with Spicer 35C Axle Multi-Lip Type

Spicer 35 axle FAG Global Number 413 2876 100

with 7.125 (in) Ring Gear with Spicer 30A Axle Independent Front Suspension

(Dana/Spicer 35 Axle)

8.25" Ring Gear FAG Global Number 413 2742 100 1.125" Shaft 1.688" Shaft

8.25 in. Ring Gear

For Use w/Dana 30/44

FAG Global Number 413 3049 100

Dana 50/30; Replacement

2.500 Shaft Diameter 4.035 Bore Diameter 4.040 Outside Diameter Seal 0.486 Width

For Use w/8.25 in. 10 Bolt Axle

Dana 44 Axle FAG Global Number 413 2950 100

1.890 Shaft Diameter 3.150 Bore Diameter 2.704 Outside Diameter Seal 0.528 Width ; Spicer Axle

with 8.25 (in) Ring Gear with Chrysler Axle

Replaces OE Part Number(s) 68004072AA with Dana Super 30 Front Axle

FAG Global Number 413 3251 100

Dana Super 30
