Oldsmobile 98 Wheel Seal Replacement

2.000 Shaft Diameter 2.560 Bore Diameter 2.565 Outside Diameter Seal 0.224 Width

1.399 Shaft Diameter 2.292 Bore Diameter 2.296 Outside Diameter Seal 0.469 Width

1.618 Shaft Diameter 2.575 Bore Diameter 2.579 Outside Diameter Seal 0.500 Width with 8.875 Ring Gear

FAG Global Number 413 3045 100

FAG Global Number 413 2468 100 1.399" Shaft

Non Pontiac Axle

Pontiac P Axle

8.875" Ring Gear FAG Global Number 413 2698 100 .70" Wide Brg. .830" Wide Brg. 1.024" Wide Brg.

1.500 Shaft Diameter 2.374 Bore Diameter 2.378 Outside Diameter Seal 0.500 Width

1.734 Shaft Diameter 2.328 Bore Diameter 2.332 Outside Diameter Seal 0.270 Width ; Exc. H.D.

1.688 Shaft Diameter 2.551 Bore Diameter 2.556 Outside Diameter Seal 0.470 Width with 8.5 Ring Gear ; B, O Axles

FAG Global Number 413 2568 100

2.000 Shaft Diameter 2.968 Bore Diameter 2.972 Outside Diameter Seal 0.313 Width

2.000 Shaft Diameter 2.962 Bore Diameter 2.966 Outside Diameter Seal 0.250 Width

without Heavy Duty Brakes

FAG Global Number 413 2842 100

1.524 Shaft Diameter 2.374 Bore Diameter 2.378 Outside Diameter Seal 0.375 Width

B,O Axles 8.50" Ring Gear FAG Global Number 413 2738 100 1.688" Shaft

FAG Global Number 413 3061 100

FAG Global Number 413 3062 100

1.875 Shaft Diameter 2.868 Bore Diameter 2.872 Outside Diameter Seal 0.544 Width with 8.5 Ring Gear ; 9.375" Ring Gear

1.524 Shaft Diameter 2.714 Bore Diameter 2.718 Outside Diameter Seal 0.500 Width

Standard Axle - 11 in. Disc

FAG Global Number 413 2593 100
