Pontiac Firebird Wheel Seal Replacement

8.875" Ring Gear Pontiac Axle

2.000 Shaft Diameter 2.560 Bore Diameter 2.565 Outside Diameter Seal 0.224 Width

1.399 Shaft Diameter 2.292 Bore Diameter 2.296 Outside Diameter Seal 0.469 Width

1.734 Shaft Diameter 2.401 Bore Diameter 2.405 Outside Diameter Seal 0.210 Width

1.618 Shaft Diameter 2.575 Bore Diameter 2.579 Outside Diameter Seal 0.500 Width with 8.875 Ring Gear

FAG Global Number 413 3045 100

FAG Global Number 413 2468 100 1.399" Shaft

FAG Global Number 413 2775 100

Non 7.75 in. Ring Gear

w/ 7.625" Ring Gear

with 7.75 (in) Ring Gear

w/ 7.625" Ring Gear

7.75 in. Ring Gear

w/ 7.625" Ring Gear

with 7.75 (in) Ring Gear

8.875" Ring Gear FAG Global Number 413 2698 100 .70" Wide Brg. .830" Wide Brg. 1.024" Wide Brg.

1.734 Shaft Diameter 2.328 Bore Diameter 2.332 Outside Diameter Seal 0.270 Width

1.688 Shaft Diameter 2.551 Bore Diameter 2.556 Outside Diameter Seal 0.470 Width with 8.5 Ring Gear ; B, O Axles

1.688 Shaft Diameter 2.551 Bore Diameter 2.556 Outside Diameter Seal 0.375 Width ; 10 Bolt Cvr.

with Drum Brakes

FAG Global Number 413 2842 100

B,O Axles 8.50" Ring Gear FAG Global Number 413 2738 100 1.688" Shaft

10 Bolt Cover FAG Global Number 413 2024 100

FAG Global Number 413 2383 100
