Volkswagen Beetle Transmission Clutch Kit Replacement

Standard; Kit Only; O.D : 7 7/8 ;I.D : 13/16 ;TEETH : 24T

Diaphragm; Dampened Disc; 7 7/8 Inch Clutch Diameter; 24 Tooth Spline; 13/16 Inch Input Shaft Diameter

Optional Kit/Rigid Hub Disc; Kit Only; O.D : 7 7/8 ;I.D : 13/16 ;TEETH : 24T

Standard; Kit Only; O.D : 7 7/8 ;I.D : 13/16 ;TEETH : 24T To 7/70

Optional Kit/Rigid Hub Disc; Kit Only; O.D : 7 7/8 ;I.D : 13/16 ;TEETH : 24T To 7/70

If replacing a Sachs clutch, all components must be replaced including the flywheel. LuK and Sachs components cannot be mixed. Refer to LB212 regarding replacement of Sachs version with LuK

200 mm Diameter; Spring Center Disc; Early Release Bearing; IAP Performance

Optional Kit/Rigid Hub Disc; Kit Only; O.D : 7 1/8 ;I.D : 13/16 ;TEETH : 24T

Standard; Kit Only; O.D : 7 1/8 ;I.D : 13/16 ;TEETH : 24T

9" Disc; 28 Spline

200 mm Diameter; Spring Center Disc; Late Release Bearing; IAP Performance

200 mm Diameter; Spring Center Disc; Late Release Bearing; SACHS

To Chassis/VIN # 1C-Y-497 071; Diaphragm; For OE Dual Mass Flywheel System; 8 5/8 Inch Clutch Diameter; 28 Tooth Spline; 7/8 Inch Input Shaft Diameter

Diaphragm; For OE Dual Mass Flywheel System; 9 Inch Clutch Diameter; 28 Tooth Spline; 7/8 Inch Input Shaft Diameter

Standard; Kit Only; O.D : 8 3/4 ;I.D : 7/8 ;TEETH : 28T

7-1/4" Disc; 24 Spline

w/ Original Equipment Clutch

Diaphragm; For OE Dual Mass Flywheel System; 9 7/16 Inch Clutch Diameter; 23 Tooth Spline; 15/16 Inch Input Shaft Diameter Slave Cylinder Is Included With Release Bearing

Slave Cylinder included Refer to LB163 regarding internal slave cylinders

Standard; Must Use w/SACHS DMF; Kit Only; O.D : 9 ;I.D : 7/8 ;TEETH : 28T

Disc Size: 8 1/2 x 7/8 x 28

HEC Tech Disc Size: 9 1/8 x 7/8 x 28 Luk Type

Standard; (fr. ch. #1C-Y-497 072) Kit w/o DMF; Kit Only; O.D : 8 7/8 ;I.D : 7/8 ;TEETH : 28T

Disc Size: 8 7/8 x 7/8 x 28

Flywheel included

w/ 228mm Flywheel

Standard; use with SACHS DMF; Kit includes Concentric Slave Cylinder.;Kit Only; O.D : 9 7/16 ;I.D : 15/16 ;TEETH : 23T

Standard; SACHS Kit w/ DMF; Kit Only; O.D : 9 ;I.D : 7/8 ;TEETH : 28T

Standard; w/ Solid Flywheel; Kit Only; O.D : 9 ;I.D : 7/8 ;TEETH : 28T

LuK Clutch

with 02J Transmission Code; Disc Size: 9 x 7/8 x 28 For Kit # 52255602 w/o Flywheel

Standard; Turbo; Kit Only; O.D : 9 7/8; I.D : 7/8; TEETH : 28T

Standard; Kit includes Concentric Slave Cylinder.;Kit Only; O.D : 9 7/16 ;I.D : 15/16 ;TEETH : 23T

HEC Tech Disc Size: 9 x 7/8 x 28 Sachs Type

Standard; (fr. ch. #1C-Y-497 072), Kit w/ Solid Flywheel; Kit Only; O.D : 9 ;I.D : 7/8 ;TEETH : 28T

LuK Clutch

w/ Solid Flywheel Conversion Kit Installed (Vehicle has already had a Solid Flywheel Clutch Conversion installed)

Standard; Kit Only; O.D : 9 7/8 ;I.D : 7/8 ;TEETH : 28T

Disc Size: 9 7/16 x 15/16 x 23 For Kit # 52405615 w/o Flywheel

w/ Original Equipment Clutch

Upgrade. Must use ACT or Corrado G60 flywheel (not included in kit).

Sachs Clutch

Standard; Kit Only; O.D : 9 7/16 ;I.D : 7/8 ;TEETH : 28T

Sachs Clutch

Upgrade. Must use ACT or Corrado G60 flywheel (not included in kit).

Upgrade. Must use ACT or Corrado G60 flywheel (not included in kit).

w/ Original Equipment Sachs Clutch & w/ 225mm Flywheel (Please note this Clutch Kit is only applicable to models that have been updated with a 225mm Flywheel)

w/ Original Equipment Clutch

Sachs Version; 9" Disc; 28 Spline

Upgrade. Must use ACT or Corrado G60 flywheel (not included in kit).

Upgrade. Must use ACT or Corrado G60 flywheel (not included in kit).

Solid Flywheel Conversion Kit

w/ Solid Flywheel Conversion Kit Installed (Vehicle has already had a Solid Flywheel Clutch Conversion installed)

w/ LUK Flywheel

Standard; LuK Kit; Kit includes Concentric Slave Cylinder.;Kit Only; O.D : 9 29/64 ;I.D : 15/16 ;TEETH : 23T

Standard; (fr. ch. #1C-Y-497 072), Kit w/ DMF; Kit Only; O.D : 8 7/8 ;I.D : 7/8 ;TEETH : 28T

Solid Flywheel Conversion Kit

Solid Flywheel Conversion Kit

Dual Mass Flywheel / Clutch Conversion - Kit contains: 240mm solid flywheel (1): pressure plate (1): clutch disc (1): Clutch Slave Cylinder - Release Bearing and flywheel mounting bolts. ***This solid flywheel replaces the OE dual mass flywheel***
