Volkswagen Transporter Engine Coolant Hose Replacement

Oil Cooler Feed Pipe to Oil Cooler

Water Thermostat Housing to lower pipe for oil cooler.

Thermostat Housing to Main Coolant Pipe

Water Pump to upper pipe for oil cooler. At pump.

Chas: 089 113-, Water Pump to "H" Connector, 025 121 438.

Chas: 022 957-, Water RT Cylinder Head To Distribution Unit. (251 121 438B)

Chas: 089 113-, Water Pipe to Double "T" for expansion tank.

Water Thermostat housing to water pump pipe. At thermostat housing.

Water Thermostat Housing to distibution connector.

Water Cylinder Head Elbow. Left rear of head. With A/C or A/C prep.

Radiator Return Pipe to Thermostat Housing
