Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.
| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.76, 70.1 |
| Conventional Or Drum In Hat Type Rotor | Conventional |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 0.827, 21 |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 114.3, 4.5 |
| Mounting Bolt Hole Diameter | 0.5, 12.7 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.905, 23 |
| Overall Height | 1.85, 47 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| GS | Hatchback | 1997 - 2001 | L4 1.8L | FWD Automatic & Manual |
| GS | Sedan | 1997 - 2001 | L4 1.8L | FWD Automatic & Manual |
| GS-R | Hatchback | 1997 - 2001 | L4 1.8L | FWD Manual |
| GS-R | Sedan | 1997 - 2001 | L4 1.8L | FWD Manual |
| LS | Hatchback | 1997 - 2001 | L4 1.8L | FWD Automatic & Manual |
| LS | Sedan | 1997 - 2001 | L4 1.8L | FWD Automatic & Manual |
| RS | Hatchback | 1997 - 1998 | L4 1.8L | FWD Automatic & Manual |
| Type R | Hatchback | 1997 - 2001 | L4 1.8L | FWD Manual |
We offer fast, reliable shipping on all orders:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
We want you to be 100% satisfied with your purchase. That's why we offer:
| Brand | Part Number |
|---|---|
| Advance Auto Parts | YH141513 |
| Advance Auto Parts | YH141513C |
| Advance Auto Parts | YH141513P |
| Altrom Imports | A03296 |
| American Remanufactured | 789-08027 |
| American Remanufactured | 89-08027 |
| Autopart International | 78295 |
| Autospecialty | JBR528 |
| Autospecialty | JBR528E |
| Autoxtra | 809177 |
| Autoxtra | AX3296 |
| AutoZone | 3296B |
| AutoZone | 3296DG |
| AutoZone | DL3296 |
| Beck/Arnley | 080-2433 |
| Beck/Arnley | 083-2433 |
| Beck/Arnley | 083-2719 |
| Beck/Arnley | 083-2734 |
| Bendix | 141513 |
| Bosch | RBR3296 |
| Brake Headquarters | BR02037 |
| Brake Pro | 4613296 |
| BrakeBest | 26010735 |
| BrakeBest | 81-125518 |
| BrakeBest | 9177 |
| BrakeBest | 9177FZN |
| BrakeBest | 9177R |
| BrakeBest | 9177RGS |
| Brembo | 09.6893.10 |
| Brembo | 25464 |
| California Drum & Rotor | 125219 |
| California Drum & Rotor | 125518 |
| Casting Numbers | 210514-C |
| Casting Numbers | 325106 |
| Casting Numbers | 32961 |
| Centric Parts | 120.40026 |
| Centric Parts | 120.40026CRY |
| Centric Parts | 121.40026 |
| Centric Parts | 125.40026 |
| Centric Parts | 126.40026CSL |
| Centric Parts | 126.40026CSR |
| Centric Parts | 126.40026SL |
| Centric Parts | 126.40026SR |
| Centric Parts | 127.40026CL |
| Centric Parts | 127.40026CR |
| Centric Parts | 127.40026L |
| Centric Parts | 127.40026R |
| Centric Parts | 128.40026CL |
| Centric Parts | 128.40026CR |
| Centric Parts | 128.40026L |
| Centric Parts | 128.40026R |
| Centric Parts | 227.40026L |
| Centric Parts | 227.40026R |
| Centric Parts | 320.40026 |
| Centric Parts | 321.40026 |
| Century | 9690 |
| Continental-ContiTech | CW23104 |
| Delphi | RB366 |
| Dura Corp | BR3296 |
| EIS Brakes | D17684 |
| Eurorotor | HO558 |
| General Motors | 86203055 |
| Guardian | 52-125219 |
| Guardian | 52-125518 |
| Honda | 45251S2HN00 |
| Honda | 45251SP0000 |
| Honda | 45251SZ3000 |
| Isuzu | 5862030550 |
| ITM Engine Components | 1601010 |
| MCI | 3706 |
| Midas | BR1741 |
| Mighty Distributing System | 3296 |
| NAPA BRAKES | SDK6237 |
| NAPA BRAKES | TSR478 |
| NAPA BRAKES | TSR693 |
| Omnicraft | QBRR116 |
| Parts Master | P125518 |
| PowerStop | JBR528EVC |
| Promax | 14-3296 |
| Qualitee International | 64-71-090 |
| Quality Brand | Q201 |
| Quinton Hazell | BDC4809 |
| Roadmates | 526679 |
| TruStar | 471090 |
| TruStar | R71090 |
| TRW | 4028 |
| TRW | DF4028S |
| TRW | DF4441S |
| Ultra Brake | HO-558 |
| Universal | 115960 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X50629 |
| WABCO - Archived | PS125518 |
| Wagner Brake | BD125219 |
| Wagner Brake | BD125518 |
| Wagner Brake | BD125518E |
| Winhere | 442144 |
| Winhere | YH2144 |
Fits Years: 1997 1998 1999 2000 2001
Fits Models: Integra
