| Attribute | Value |
|---|---|
| Coolant Hose Inlet Connection Type | Oe Type Connection |
| Coolant Hose Outlet Connection Type | Oe Type Connection |
| Core Height | 25.5625 In. |
| Core Material | Aluminum |
| Core Row Quantity | 2 |
| Core Thickness | 1.625 In. |
| Core Width | 17.3125 In. |
| Down Flow Or Cross Flow Type | Cross Flow |
| Finish/Color | Satin |
| Frame Included | No |
| Grade Type | Performance |
| Inlet Connector Type | Quick Connect |
| Inlet Diameter | 1.25 In. |
| Inlet Location | Top Left |
| Installation Type | Drop-in Fit Installation |
| Internal Engine Oil Cooler | No |
| Internal Transmission Oil Cooler | No |
| Mounting Hardware Included | No |
| Mounting Type | Mounts With Oe Hardware |
| Outlet Connector Type | Quick Connect |
| Outlet Diameter | 1.25 In. |
| Outlet Location | Bottom Right |
| Radiator Cap Included | No |
| Tank Material | Aluminum |
| Thermostat Included | No |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Attraction | Convertible | 2018 | L4 1.8L Turbo | FWD Automatic Dual Clutch |
| Dynamic | Hatchback | 2017 | L4 1.4L Turbo | FWD Manual & Automatic Dual Clutch |
| Dynamic | Hatchback | 2017 | L4 2.0L Turbo | FWD Manual & Automatic Dual Clutch |
| Dynamic | Sedan | 2017 - 2020 | L4 1.4L Turbo | FWD Automatic Dual Clutch |
| Dynamic | Sedan | 2017 | L4 1.4L Turbo | FWD Manual |
| Dynamic | Sedan | 2017 - 2020 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Dynamic | Sedan | 2017 | L4 2.0L Turbo | FWD Manual |
| Elite | Sedan | 2017 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Komfort | Convertible | 2017, 2019 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Komfort | Sedan | 2017 - 2020 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Premium | Convertible | 2017 - 2019 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Premium | Sedan | 2017 - 2020 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Premium Plus | Convertible | 2017 - 2019 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Premium Plus | Sedan | 2017 - 2020 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Prestige | Convertible | 2017 - 2019 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Prestige | Sedan | 2017 - 2019 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Progressiv | Convertible | 2017, 2019 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Progressiv | Sedan | 2017 - 2020 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| S Line | Convertible | 2018 | L4 1.8L Turbo | FWD Automatic Dual Clutch |
| S Line | Convertible | 2018 - 2020 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| S Line | Hatchback | 2017 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| S Line | Sedan | 2018 | L4 1.8L Turbo | FWD Automatic Dual Clutch |
| S Line | Sedan | 2017 - 2020 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Select | Convertible | 2019 - 2020 | L4 1.4L Turbo | FWD Automatic Dual Clutch |
| Select | Convertible | 2019 - 2020 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Select | Hatchback | 2017 | L4 1.4L Turbo | FWD Automatic Dual Clutch |
| Select | Hatchback | 2017 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Select | Sedan | 2017 - 2020 | L4 1.4L Turbo | FWD Automatic Dual Clutch |
| Select | Sedan | 2017 - 2020 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Technik | Convertible | 2017, 2019 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Technik | Sedan | 2017, 2020 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Titanium | Sedan | 2019 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
Fits Years: 2017 2018 2019 2020
Fits Models: A3
