| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.56, 65 |
| Conventional Or Drum In Hat Type Rotor | Conventional |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 0.748, 19 |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 3.93, 99.8 |
| Mounting Bolt Hole Diameter | 0.625, 15.9 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.865, 21.95 |
| Overall Height | 1.435, 36.45 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Advance | Hatchback | 2002 - 2004 | L4 1.8L Turbo | FWD Automatic & Manual |
| Ambiente | Hatchback | 2004 | L4 2.0L | FWD Automatic & Manual |
| Ambiente | Hatchback | 2004 | L4 2.0L Turbo | FWD Automatic & Manual |
| Ambiente | Hatchback | 2001 - 2003 | L4 1.8L Turbo | FWD Automatic & Manual |
| Ambition | Hatchback | 2000 - 2001 | L4 1.8L Turbo | FWD Automatic & Manual |
| Attraction | Hatchback | 2004 | L4 2.0L | FWD Automatic & Manual |
| Attraction | Hatchback | 2004 | L4 2.0L Turbo | FWD Automatic & Manual |
| Attraction | Hatchback | 2000 - 2003 | L4 1.8L Turbo | FWD Automatic & Manual |
| Attraction Plus | Hatchback | 2004 | L4 2.0L | FWD Automatic & Manual |
| Attraction Plus | Hatchback | 2004 | L4 2.0L Turbo | FWD Automatic & Manual |
| Base | Hatchback | 1998 - 1999 | L4 1.8L Turbo | FWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Advance Auto Parts | N1000385262ZIC |
| Advance Auto Parts | YH145239 |
| Advance Auto Parts | YH145239C |
| Advance Auto Parts | YH145239P |
| Altrom Imports | A34143 |
| American Remanufactured | 89-96042 |
| Autospecialty | EBR615 |
| Autospecialty | EBR615E |
| Autospecialty | EBR636 |
| Autoxtra | 125740 |
| Autoxtra | 8096778 |
| Autoxtra | AX341143 |
| Autoxtra | AX34143 |
| AutoZone | 34143DG |
| AutoZone | DL34143 |
| Beck/Arnley | 083-2750 |
| Bendix | 145239 |
| BrakeBest | 53011382 |
| BrakeBest | 53011384 |
| BrakeBest | 81-125740 |
| BrakeBest | 96778 |
| BrakeBest | 96778FZN |
| BrakeBest | 96778R |
| BrakeBest | 96778RGS |
| Brembo | 09.7012.10 |
| Brembo | 09.7012.80 |
| Brembo | 25536 |
| California Drum & Rotor | 125647 |
| Casting Numbers | 211213-C |
| Casting Numbers | 325114 |
| Centric Parts | 120.33054 |
| Centric Parts | 121.33054 |
| Centric Parts | 125.33054 |
| Centric Parts | 125.33054CRY |
| Centric Parts | 126.33054CSL |
| Centric Parts | 126.33054CSR |
| Centric Parts | 126.33054SL |
| Centric Parts | 126.33054SR |
| Centric Parts | 127.33054L |
| Centric Parts | 127.33054R |
| Centric Parts | 128.33054CL |
| Centric Parts | 128.33054CR |
| Centric Parts | 128.33054L |
| Centric Parts | 128.33054R |
| Centric Parts | 227.33054L |
| Centric Parts | 227.33054R |
| Centric Parts | 320.33054 |
| Centric Parts | 320.33054C |
| Centric Parts | 320.33054H |
| Continental-ContiTech | CW22150 |
| Dura Corp | BR34143 |
| Dura Corp | BR3414302 |
| Guardian | 52-125647 |
| Guardian | 52-125740 |
| Mighty Distributing System | 34143 |
| NAPA BRAKES | SDK6089 |
| NAPA BRAKES | TSR2804 |
| PowerStop | EBR615EVC |
| Promax | 14-34143 |
| Promax | 20-34143 |
| Qualitee International | 64-16-220 |
| Quality Brand | Q218 |
| Quinton Hazell | BDC4668 |
| TruStar | 416220 |
| TruStar | R16220 |
| TRW | DF2804S |
| Universal | 117202 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51283 |
| Volkswagen | 180615301 |
| Volkswagen | 1J0615301M |
| Volkswagen | 1J0615301P |
| WABCO - Archived | PS125740 |
| Wagner Brake | BD125647 |
| Wagner Brake | BD125740 |
| Wagner Brake | BD125740E |
| Winhere | 662573 |
| Winhere | YH2573 |
Fits Years: 1998 1999 2000 2001 2002 2003 2004
Fits Models: A3
