| Attribute | Value |
|---|---|
| 4181 ABS Tone Ring Included | No |
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.68, 68.00 |
| Construction | Composite, Full Cast |
| Discard Thickness | 10.00 |
| Grade Type | Premium |
| Material | Gray Cast Iron |
| Nominal Thickness | 12.00 |
| Overall Height | 1.42, 36.00 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| Weight | 5.2 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Convertible | 2014 | V6 3.0L Supercharged | AWD Manual & Automatic Dual Clutch |
| Base | Coupe | 2013 - 2014 | V6 3.0L Supercharged | AWD Automatic Dual Clutch |
| Base | Coupe | 2012 - 2016 | V6 3.0L Supercharged | AWD Manual |
| Base | Coupe | 2008 - 2012 | V8 4.2L | AWD Automatic & Manual |
| Base | Hatchback | 2014 - 2016 | V6 3.0L Supercharged | AWD Manual |
| Cabriolet | Convertible | 2010 - 2013 | V6 3.0L Supercharged | AWD Automatic Dual Clutch |
| Premium Plus | Convertible | 2014 - 2016 | V6 3.0L Supercharged | AWD Manual & Automatic Dual Clutch |
| Premium Plus | Coupe | 2014 - 2016 | V6 3.0L Supercharged | AWD Manual & Automatic Dual Clutch |
| Prestige | Convertible | 2014 - 2016 | V6 3.0L Supercharged | AWD Manual & Automatic Dual Clutch |
| Prestige | Coupe | 2014 - 2016 | V6 3.0L Supercharged | AWD Manual & Automatic Dual Clutch |
| Progressiv | Convertible | 2015 - 2016 | V6 3.0L Supercharged | AWD Manual & Automatic Dual Clutch |
| Progressiv | Coupe | 2015 - 2016 | V6 3.0L Supercharged | AWD Manual & Automatic Dual Clutch |
| Technik | Convertible | 2015 - 2016 | V6 3.0L Supercharged | AWD Manual & Automatic Dual Clutch |
| Technik | Coupe | 2015 - 2016 | V6 3.0L Supercharged | AWD Manual & Automatic Dual Clutch |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Aimco | 34403 |
| Aimco | 45454 |
| ATE | 24011201781 |
| Beck/Arnley | 083-3321 |
| Bosch | 0986479382 |
| Bosch | 0986UB1721 |
| Centric Parts | 120.33127 |
| Centric Parts | 121.33127 |
| Centric Parts | 125.33127 |
| DuraGo | BR900808 |
| DuraGo | BR90080801 |
| DuraGo | BR90080802 |
| Ferodo | DDF1666C |
| NAPA Proformer | PFR 248880694 |
| PAGID Racing | 355113932 |
| Raybestos Brakes | 980694 |
| Raybestos Brakes | 980694FZN |
| Raybestos Brakes | 980694R |
| Textar | 92160103 |
| TRW | DF4848 |
| Volkswagen | 8KD615601 |
| Wagner Brake | BD180106 |
| Wagner Brake | BD180106E |
| Winhere | 441775 |
| Zimmermann | 100.3333.20 |
| Zimmermann | 100333320 |
Fits Years: 2008 2009 2010 2011 2012 2013 2014 2015 2016
Fits Models: S5
