| Attribute | Value |
|---|---|
| 112.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 4.41 |
| Bolt Hole Circle Ø [mm] | 112 |
| Bolt Hole Quantity | 5 |
| Brake Disc Thickness [in] | 0.87 |
| Brake Disc Type | Externally Vented |
| California Proposition 65 Required | No |
| Center Hole Diameter | 112.0 |
| Centering Diameter [in] | 2.68 |
| Color | Silver |
| Colour | Silver |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 20.00 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Hole Arrangement / Number | 05/05 |
| Hole Arrangement/Number | 05/05 |
| Inside Diameter | 68.0 |
| Machining | High-carbon |
| Material | Gray Cast Iron |
| Minimum Thickness [in] | 0.79 |
| Minimum Thickness [mm] | 20 |
| Mounting Bolt Hole Circle Diameter | 112.00 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 22.00 |
| Outer Diameter [in] | 10.59 |
| Overall Height | 53.70 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 54768pro_hc_na |
| Weight [kg] | 5,3, 5.3 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Avant | Wagon | 2002 - 2003 | V8 4.2L | AWD Automatic |
| Base | Sedan | 2002 - 2003 | V8 4.2L | AWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Akebono | BN0707 |
| Akebono | BN0707E |
| ATE | 24012202221 |
| ATE | 422222 |
| Bendix | 521228 |
| Bendix | 562515BC |
| Bendix | BR4241EURO |
| Blue Print | ADV1843102 |
| Borg & Beck | BBD4684 |
| Bosch | 0986479A42 |
| Brake Engineering | DI956710 |
| Brembo | 09D23011 |
| Cifam | 8001517C |
| Delphi | BG4057 |
| DON | PCD14432 |
| Dynamic Friction Company | 600-74023 |
| Dynamic Friction Company | 604-74023 |
| Dynamic Friction Company | 900-74023 |
| EBC Brakes | D1417 |
| EBC Brakes | GD1417 |
| EBC Brakes | USR1417 |
| Febi-Bilstein | 43869 |
| Ferodo | DDF2151C |
| Ferodo | DDF2151C1 |
| FTE | 9072335 |
| FTE | BS7292 |
| Girling | 6043522 |
| Hella Pagid | 54768PROHCNA |
| Hella Pagid | 8DD355115442 |
| JP Group A/S | 1163207800 |
| Jurid | 562515JC |
| METELLI | 231517C |
| MEYLE | 1155230008PD |
| Mintex | MDC1921 |
| NK Autoparts | 2047158 |
| NK Autoparts | 3147158 |
| Optimal | BS8778 |
| Optimal | BS8778C |
| PAGID Racing | 54768 |
| PAGID Racing | 54768PRO |
| Remsa | 6136310 |
| SBS | 18152047158 |
| Skoda | 4B6 156 01 |
| Textar | 92176800 |
| Textar | 92176803 |
| Textar | 92176805 |
| Textar | 98200176801 |
| TRW | DF4352 |
| TRW Steering and Suspension Parts | DF4352S |
| VAICO | V1080109 |
| Valeo | 197089 |
| Volkswagen | 4B3 361 601 |
| Zimmermann | 100333700 |
| Zimmermann | 100333720 |
| Zimmermann | 100333770 |
| Zimmermann | 100333772 |
| Zimmermann | 100333775 |
Fits Years: 2002 2003
Fits Models: S6
