| Attribute | Value |
|---|---|
| Bypass Flange Diameter | 1.09 |
| Bypass Flange Length | 1.09 |
| Flange Height | .65 |
| Flange Thickness | .06 |
| Gasket Quantity | 0 |
| Grade Type | Oe Performance |
| Height Between Flanges | 1.5 |
| Installation Tool Included | No |
| Jiggle Pin Check Valve Quantity | 0 |
| Jiggle Pin Weep Hole | No |
| Material | Stainless Steel |
| Seal Quantity | 0 |
| Sealing Flange Outside Diameter | 2.12 |
| Start To Open Temperature | 180, 82 |
| Type | Oe Type Thermostat |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Standard Cargo Van | 1985 - 1986 | L4 2.5L | RWD Automatic & Manual |
| Base | Standard Cargo Van | 1985 - 1986 | V6 4.3L | RWD Automatic & Manual |
| Base | Standard Passenger Van | 1985 - 1986 | L4 2.5L | RWD Automatic & Manual |
| Base | Standard Passenger Van | 1985 - 1986 | V6 4.3L | RWD Automatic & Manual |
| CL | Standard Passenger Van | 1985 | L4 2.5L | RWD Automatic & Manual |
| CL | Standard Passenger Van | 1985 - 1986 | V6 4.3L | RWD Automatic & Manual |
| CS | Standard Passenger Van | 1985 | L4 2.5L | RWD Automatic & Manual |
| CS | Standard Passenger Van | 1985 - 1986 | V6 4.3L | RWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Amgauge | 339-180 |
| Arenco | 48-1008 |
| Atlas | 644-325 |
| Atlas | 644-332 |
| Atlas | 644-356 |
| Autotemp | 12-180 |
| Autotemp | 24-180 |
| BAP Geon | 28-10182 |
| BAP Geon | 28-16081 |
| BAP Geon | 28-16083 |
| BAP Geon | 28-16380 |
| BAP Geon | 28-16381 |
| BAP Geon | 28-16382 |
| BAP Geon | 28-19180 |
| BAP Geon | 28-19182 |
| Beck/Arnley | 143-0347 |
| Beck/Arnley | 143-0388 |
| Beck/Arnley | 143-0628 |
| British Leyland | GTS103 |
| British Leyland | JLM9634 |
| Calterm | VB28-V5448 |
| Calterm | VB28-V6360 |
| Calterm | VB28-V6475 |
| Calterm | VB28-V6813 |
| Carquest Premium Caps and Stats | 13398 |
| Carter | 26-1298 |
| CEW | 4006 082 |
| CEW | 4062 181 |
| Chrysler | 4167217 |
| Chrysler | MD094120 |
| Chrysler | ME007183 |
| CST | 27780 |
| CST | 3068 |
| CST | 3397 |
| CST | 7228-180 |
| CST | 7272-180 |
| Datsun/Nissan | 2120016A00 |
| Datsun/Nissan | 2120896002 |
| Dayco | 83155 |
| Dayco | 83235 |
| Eaton | ET-10-180 |
| Eaton | ET-12-180 |
| Eaton | ET-18-180 |
| Eaton | ET-23-180 |
| Edelmann | 2041-180 |
| Edelmann | E-139-180 |
| General Motors | 12302412 |
| General Motors | 1338024 |
| Ideal Tridon | 31058 |
| Ideal Tridon | 31168 |
| Ideal Tridon | 32188 |
| International Harvester IHC | 3059676R1 |
| International Harvester IHC | 3228046R1 |
| International Harvester IHC | 3228046R3 |
| Isuzu | 8942149620 |
| Isuzu | 8970898910 |
| Isuzu | 8973617700 |
| Isuzu | 97361770 |
| John Deere | AR61538 |
| Lazorlite | L33-9073 |
| Lazorlite | L33-9363 |
| Lazorlite | U33-9212 |
| Massey Ferguson | 1446043M1 |
| Massey Ferguson | 1446043M91 |
| Mazda | 082315171A |
| Mazda | 083915171A |
| Mazda | 817315171 |
| Mazda | 818315171 |
| Mazda | 855315171 |
| Mazda | 855399152 |
| Mazda | 8ABE15173 |
| Mazda | 8AF115171 |
| Mazda | SE0115171 |
| Mazda | SE0899152 |
| Mitsubishi | MD005299 |
| Mitsubishi | MD015299 |
| Mitsubishi | MD071347 |
| Motorad | 272-180 |
| Motorcraft | RT-1045 |
| Motorcraft | RT-306 |
| Murray Temperature Control | 277098 |
| Murray Temperature Control | 277158 |
| NAPA Belts/Hose | 33188 |
| Perkins | 2485604 |
| Robertshaw | 312-180 |
| Robertshaw | 323-180 |
| Robertshaw | 324-180 |
| Robertshaw | 326-180 |
| Robertshaw | 328-180 |
| Robertshaw | 347-180 |
| Robertshaw | 368-180 |
| Robertshaw | 369-180 |
| Robertshaw | 390-180 |
| Robertshaw | 412-180 |
| Robertshaw | 423-180 |
| Robertshaw | 424-180 |
| Robertshaw | 426-180 |
| Robertshaw | 428-180 |
| Robertshaw | 447-180 |
| Standard Thomson | 139 |
| Stant | 29398 |
| Stant | 35398 |
| Stant | S-339-180 |
| Tridon | 522880 |
| Tridon | 542480 |
| Tridon | 542780 |
| Tru-Temp | 663HT |
| UD | 2120005D02 |
| Wahler | 4022.82 |
| Wahler | 4095.83 |
| Wahler | 4103.82 |
| Waltham | W139 |
| Worldparts | 143-0081 |
| Worldparts | W57-125 |
Fits Years: 1985 1986
Fits Models: Astro
