| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Bearings Included | No |
| Cross Drilled | No |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 0.96, 24.5 |
| Inner Bearing Cup Included | Yes |
| Mounting Bolt Hole Circle Diameter | 127, 5 |
| Nominal Thickness | 1.04, 26.3 |
| Outer Bearing Cup Included | Yes |
| Overall Height | 118.2, 4.65 |
| Rotor Outside Diameter | 11.85, 301 |
| Rust Resistant Coating | No |
| Slotted | No |
| Solid Or Vented Type Rotor | Vented |
| Stud Quantity | 5 |
| Stud Thread Size | 1/2-20 |
| Wheel Studs Included | Yes |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Extended Cargo Van | 1990 | L4 2.5L | AWD/RWD Automatic |
| Base | Extended Cargo Van | 1990 - 1993 | V6 4.3L | AWD/RWD Automatic |
| Base | Standard Cargo Van | 1990 | L4 2.5L | AWD Automatic |
| Base | Standard Cargo Van | 1990 - 1993 | V6 4.3L | AWD Automatic |
| Base | Standard Cargo Van | 1985 - 1990 | L4 2.5L | RWD Automatic |
| Base | Standard Cargo Van | 1985 - 1989 | L4 2.5L | RWD Manual |
| Base | Standard Cargo Van | 1985 - 1993 | V6 4.3L | RWD Automatic |
| Base | Standard Cargo Van | 1985 - 1989 | V6 4.3L | RWD Manual |
| Base | Standard Passenger Van | 1985 - 1987 | L4 2.5L | RWD Automatic & Manual |
| Base | Standard Passenger Van | 1985 - 1987 | V6 4.3L | RWD Automatic & Manual |
| CL | Extended Passenger Van | 1990 - 1993 | V6 4.3L | AWD/RWD Automatic |
| CL | Standard Passenger Van | 1990 - 1993 | V6 4.3L | AWD Automatic |
| CL | Standard Passenger Van | 1985 | L4 2.5L | RWD Automatic & Manual |
| CL | Standard Passenger Van | 1985 - 1993 | V6 4.3L | RWD Automatic |
| CL | Standard Passenger Van | 1985 - 1989 | V6 4.3L | RWD Manual |
| CS | Extended Passenger Van | 1990 - 1993 | V6 4.3L | AWD/RWD Automatic |
| CS | Standard Passenger Van | 1990 - 1993 | V6 4.3L | AWD Automatic |
| CS | Standard Passenger Van | 1985 | L4 2.5L | RWD Automatic & Manual |
| CS | Standard Passenger Van | 1985 - 1993 | V6 4.3L | RWD Automatic |
| CS | Standard Passenger Van | 1985 - 1989 | V6 4.3L | RWD Manual |
| LT | Extended Passenger Van | 1990 - 1993 | V6 4.3L | AWD/RWD Automatic |
| LT | Standard Passenger Van | 1990 - 1993 | V6 4.3L | AWD Automatic |
| LT | Standard Passenger Van | 1987 - 1993 | V6 4.3L | RWD Automatic |
| LT | Standard Passenger Van | 1987 - 1989 | V6 4.3L | RWD Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Aimco | 5546 |
| Auto Extra | AX5546 |
| Bendix | PRT1216 |
| OES Genuine | 14008641 |
| OES Genuine | 15622775 |
| OES Genuine | 15679659 |
| OES Genuine | 18016032 |
| OES Genuine | 474352 |
| Parts Master | 60476 |
| Parts Plus | P5032 |
| Raybestos Brakes | 5032 |
| Wagner Brake | BD60476 |
Fits Years: 1985 1986 1987 1988 1989 1990 1991 1992 1993
Fits Models: Astro
