Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.
| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.102, 78.8 |
| Conventional Or Drum In Hat Type Rotor | Conventional |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 1.215, 30.85 |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 127, 5 |
| Mounting Bolt Hole Diameter | 0.546, 13.85 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.285, 32.65 |
| Overall Height | 3.273, 83.15 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Extended Cargo Van | 1990 | L4 2.5L | AWD/RWD Automatic |
| Base | Extended Cargo Van | 1990 - 2002 | V6 4.3L | AWD/RWD Automatic |
| Base | Extended Passenger Van | 1997 - 2002 | V6 4.3L | AWD/RWD Automatic |
| Base | Standard Cargo Van | 1990 | L4 2.5L | AWD/RWD Automatic |
| Base | Standard Cargo Van | 1990 - 2002 | V6 4.3L | AWD/RWD Automatic |
| Base | Standard Passenger Van | 1997 - 2002 | V6 4.3L | AWD/RWD Automatic |
| CL | Extended Passenger Van | 1990 - 1995 | V6 4.3L | AWD/RWD Automatic |
| CL | Standard Passenger Van | 1990 - 1995 | V6 4.3L | AWD/RWD Automatic |
| CS | Extended Passenger Van | 1990 - 1995 | V6 4.3L | AWD/RWD Automatic |
| CS | Standard Passenger Van | 1990 - 1995 | V6 4.3L | AWD/RWD Automatic |
| LS | Extended Passenger Van | 1996 - 2002 | V6 4.3L | AWD/RWD Automatic |
| LS | Standard Passenger Van | 1996 - 2002 | V6 4.3L | AWD/RWD Automatic |
| LT | Extended Passenger Van | 1990 - 2002 | V6 4.3L | AWD/RWD Automatic |
| LT | Standard Passenger Van | 1990 - 2002 | V6 4.3L | AWD/RWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ACDelco | 177-732 |
| Advance Auto Parts | YH141745 |
| Autopartsource | 493930 |
| Autoxtra | 125050 |
| Autoxtra | AX55015 |
| AutoZone | DL55015 |
| Bosch | 25010568 |
| BrakeBest | 580442 |
| BrakeBest | 580442R |
| BrakeBest | 580442RGS |
| Bridgestone | 7002446 |
| Centric Parts | 120.66022 |
| Centric Parts | 121.66022 |
| Centric Parts | 125.66022 |
| Centric Parts | 126.66022CSL |
| Centric Parts | 126.66022CSR |
| Centric Parts | 126.66022SL |
| Centric Parts | 126.66022SR |
| Centric Parts | 127.66022CL |
| Centric Parts | 127.66022CR |
| Centric Parts | 127.66022L |
| Centric Parts | 127.66022R |
| Centric Parts | 128.66022L |
| Centric Parts | 128.66022R |
| Centric Parts | 320.66022 |
| Dura Corp | BR55138 |
| DuraGo | BR55015 |
| General Motors | 15679711 |
| General Motors | 18028003 |
| Guardian | 52-125050 |
| Monroe Brakes | BD125050 |
| Newtek Automotive USA | 55138 |
| Qualis | 55015 |
| Quality Brand | 55015C |
| Quality Brand | Q4015C |
Fits Years: 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002
Fits Models: Astro
