| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.1, 78.75 |
| Conventional Or Drum In Hat Type Rotor | Drum-in-hat |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 0.728, 18.5 |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 139.7, 5.5 |
| Mounting Bolt Hole Diameter | 0.645, 16.4 |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 0.79, 20.05 |
| Overall Height | 3.35, 85.1 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 6 |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Extended Cargo Van | 2003 - 2005 | V6 4.3L | AWD/RWD Automatic |
| Base | Extended Passenger Van | 2003 - 2005 | V6 4.3L | AWD/RWD Automatic |
| Base | Standard Cargo Van | 2003 - 2005 | V6 4.3L | AWD/RWD Automatic |
| Base | Standard Passenger Van | 2003 - 2005 | V6 4.3L | AWD/RWD Automatic |
| LS | Extended Passenger Van | 2003 - 2005 | V6 4.3L | AWD/RWD Automatic |
| LS | Standard Passenger Van | 2003 - 2005 | V6 4.3L | AWD/RWD Automatic |
| LT | Extended Passenger Van | 2003 - 2005 | V6 4.3L | AWD/RWD Automatic |
| LT | Standard Passenger Van | 2003 - 2005 | V6 4.3L | AWD/RWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ACDelco | 177-859 |
| Advance Auto Parts | YH145265 |
| Advance Auto Parts | YH145265C |
| Advance Auto Parts | YH145265P |
| American Remanufactured | 89-44041 |
| API | 1407-25776 |
| Autospecialty | AR8641 |
| Autospecialty | AR8641E |
| Autoxtra | 8056827 |
| Autoxtra | AX55066 |
| AutoZone | 55066DG |
| AutoZone | 55066DL |
| AutoZone | DL55066 |
| Bendix | 145265 |
| BrakeBest | 25010532 |
| BrakeBest | 56827 |
| BrakeBest | 56827FZN |
| BrakeBest | 56827PER |
| BrakeBest | 56827R |
| BrakeBest | 56827RGS |
| BrakeBest | 81-125655 |
| Brembo | 09.8810.80 |
| Brembo | 27047 |
| California Drum & Rotor | 125655 |
| Casting Numbers | 15727132 |
| Casting Numbers | 211250-C |
| Casting Numbers | 325502 |
| Centric Parts | 120.66041 |
| Centric Parts | 120.66041CRY |
| Centric Parts | 121.66041 |
| Centric Parts | 125.66041 |
| Centric Parts | 125.66041CRY |
| Centric Parts | 126.66041CSL |
| Centric Parts | 126.66041CSR |
| Centric Parts | 126.66041SL |
| Centric Parts | 126.66041SR |
| Centric Parts | 127.66041CL |
| Centric Parts | 127.66041CR |
| Centric Parts | 127.66041L |
| Centric Parts | 127.66041R |
| Centric Parts | 128.66041L |
| Centric Parts | 128.66041R |
| Centric Parts | 227.66041L |
| Centric Parts | 227.66041R |
| Centric Parts | 320.66041 |
| Centric Parts | 321.66041 |
| Continental-ContiTech | CW20702 |
| Dura Corp | BR55066 |
| Dura Corp | BR5506602 |
| Eurorotor | 55440 |
| General Motors | 15712800 |
| General Motors | 19211496 |
| Guardian | 52-125655 |
| Mighty Distributing System | 55066 |
| Omnicraft | QBRR207 |
| Parts Master | P125655 |
| PowerStop | AR8641EVC |
| Promax | 14-55066 |
| Promax | 20-55066 |
| Quality Brand | Q4145 |
| UAP | 2055066 |
| Universal | 101899 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51315 |
| WABCO - Archived | PS125655 |
| Wagner Brake | BD125655 |
| Wagner Brake | BD125655E |
| Winhere | 662642 |
| Winhere | YH2642 |
Fits Years: 2003 2004 2005
Fits Models: Astro
