| Attribute | Value |
|---|---|
| Cableado Incluido | Sí |
| Connector Color | Blanco, White |
| Connector Gender | Female, Hembra |
| Connector Shape | Ovalado |
| Contenidos Del Paquete | 1ensamble Del Módulo De La Bomba Del Combustible |
| Fuel Sending Unit Included | Oui, Sí, Yes |
| Fuel Tank Pressure Sensor Included | Oui, Sí, Yes |
| Fuel Type | Gas |
| Gasket Or Seal Included | Oui, Sí, Yes |
| Gasket Or Seal Material | Caucho, Élastomère, Rubber |
| Grade Type | Regular |
| Housing Length | 175 |
| Housing Width | 95 |
| Inlet Outside Diameter | 7.9 |
| Inlet Quantity | 1, 1 Ensamble De Manguera Del Calentador |
| Internal Or External Strainer | Internal, Interno |
| Lock Ring Included | No, Non |
| Maximum Flow Rating | 97 Gph |
| Maximum Pressure | 80 |
| Minimum Free Flow Rate | 160 |
| Minimum Pressure | 43 |
| Mounting Hardware Included | No, Non |
| Negative Ground | Oui, Sí, Yes |
| Outlet Diameter | 5.8 Mm |
| Outlet Outside Diameter | 9.5 |
| Outlet Quantity | 1, 1 Ensamble De Manguera Del Calentador |
| Pump Design | Electric In-tank, Eléctrico, Dentro Del Tanque |
| Pump Type | Electric, Eléctrico |
| Regulator Included | No, Non |
| Resistance Ohms Empty | 39 |
| Resistance Ohms Full | 250 |
| Strainer Included | Oui, Sí, Yes |
| Terminal Gender | Macho, Male |
| Terminal Quantity | 3, 4 |
| Terminal Type | Blade Pin, Pasador De Aspa |
| Top Mount Diameter | 113 |
| Voltage | 15 |
| Wire Harness Included | Oui, Yes |
| Wire Quantity | 4 |
| Wiring Harness Length | 400 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Extended Cargo Van | 1997 - 1999 | V6 4.3L | AWD/RWD Automatic |
| Base | Extended Passenger Van | 1997 - 1999 | V6 4.3L | AWD/RWD Automatic |
| Base | Standard Cargo Van | 1997 - 1999 | V6 4.3L | AWD/RWD Automatic |
| Base | Standard Passenger Van | 1997 - 1999 | V6 4.3L | AWD/RWD Automatic |
| LS | Extended Passenger Van | 1997 - 1999 | V6 4.3L | AWD/RWD Automatic |
| LS | Standard Passenger Van | 1997 - 1999 | V6 4.3L | AWD/RWD Automatic |
| LT | Extended Passenger Van | 1997 - 1999 | V6 4.3L | AWD/RWD Automatic |
| LT | Standard Passenger Van | 1997 - 1999 | V6 4.3L | AWD/RWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Airtex | E3940M |
| Carter | P74752M |
| Delphi | FG0068 |
| General Motors | 19180091 |
| General Motors | 25178736 |
| General Motors | 25314776 |
| General Motors | 25320523 |
| Spectra Premium | SP413M |
| TYC | 150009 |
Fits Years: 1997 1998 1999
Fits Models: Astro
