| Attribute | Value |
|---|---|
| Bolt Circle Diameter | 127.000, 5.000 |
| Brake Pilot Diameter | 3.080 |
| Flange Bolt Hole Quantity | 3 |
| Flange Offset | 2.940 |
| Flange Shape | Triangular |
| Hub Pilot Diameter | 3.910 |
| Spline Quantity | 33 |
| Wheel Pilot Diameter | 3.060 |
| Wheel Stud Quantity | 5 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Extended Cargo Van | 1995 - 2002 | V6 4.3L | AWD/RWD Automatic |
| Base | Extended Passenger Van | 1997 - 2002 | V6 4.3L | AWD/RWD Automatic |
| Base | Standard Cargo Van | 1995 - 2002 | V6 4.3L | AWD/RWD Automatic |
| Base | Standard Passenger Van | 1997 - 2002 | V6 4.3L | AWD/RWD Automatic |
| CL | Extended Passenger Van | 1995 | V6 4.3L | AWD/RWD Automatic |
| CL | Standard Passenger Van | 1995 | V6 4.3L | AWD/RWD Automatic |
| CS | Extended Passenger Van | 1995 | V6 4.3L | AWD/RWD Automatic |
| CS | Standard Passenger Van | 1995 | V6 4.3L | AWD/RWD Automatic |
| LS | Extended Passenger Van | 1996 - 2002 | V6 4.3L | AWD/RWD Automatic |
| LS | Standard Passenger Van | 1996 - 2002 | V6 4.3L | AWD/RWD Automatic |
| LT | Extended Passenger Van | 1995 - 2002 | V6 4.3L | AWD/RWD Automatic |
| LT | Standard Passenger Van | 1995 - 2002 | V6 4.3L | AWD/RWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ACDelco | 515019 |
| ACDelco | FW172 |
| ACDelco | FW173 |
| Centric Parts | 402.66002 |
| Centric Parts | 402.66002E |
| Drive Tech America | NT515019 |
| Fenco | WH515019 |
| General Motors | 15997073 |
| General Motors | 15997074 |
| GMB | 730-0238 |
| Mevotech | H515019 |
| Raybestos Brakes | 715019 |
| SKF | BR930209 |
| Timken | SP550302 |
| Timken | SP550303 |
| Timken | SP550308 |
Fits Years: 1995 1996 1997 1998 1999 2000 2001 2002
Fits Models: Astro
