| Attribute | Value |
|---|---|
| 127.0 | |
| Attribute ID (Type) | California Proposition 65 |
| Bolt Circle Diameter [cntrc] In | 5.000 |
| Bolt Circle Diameter [cntrc] Mm | 127.000 |
| Bolt Hole Quantity | 5 |
| Friction Surface Width [cntrc] In | 2.480 |
| Friction Surface Width [cntrc] Mm | 62.992 |
| Friction Surface Inches | 2.48 |
| Friction Surface Mm | 63.0 |
| Height [cntrc] In | 3.140 |
| Height [cntrc] Mm | 79.756 |
| Hub Hole / Register [cntrc] In | 3.100 |
| Hub Hole / Register [cntrc] Mm | 78.740 |
| Maximum Brake Diameter (Discard) | 243.59, 243.600, 9.590 |
| Mounting Hole Diameter | 0.530, 0.54, 13.462 |
| Mounting Type [cntrc] | Floating |
| Nominal Drum Diameter | 241.30, 241.300, 9.500 |
| Outer Cooling Fins | Yes |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 6.818 |
| Weight [cntrc] Lbs | 15.000 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Extended Cargo Van | 1990 | L4 2.5L | AWD/RWD Automatic |
| Base | Extended Cargo Van | 1990 - 2002 | V6 4.3L | AWD/RWD Automatic |
| Base | Extended Passenger Van | 1997 - 2002 | V6 4.3L | AWD/RWD Automatic |
| Base | Standard Cargo Van | 1990 | L4 2.5L | AWD Automatic |
| Base | Standard Cargo Van | 1990 - 2002 | V6 4.3L | AWD Automatic |
| Base | Standard Cargo Van | 1985 - 1990 | L4 2.5L | RWD Automatic |
| Base | Standard Cargo Van | 1985 - 1989 | L4 2.5L | RWD Manual |
| Base | Standard Cargo Van | 1985 - 2002 | V6 4.3L | RWD Automatic |
| Base | Standard Cargo Van | 1985 - 1989 | V6 4.3L | RWD Manual |
| Base | Standard Passenger Van | 1997 - 2002 | V6 4.3L | AWD Automatic |
| Base | Standard Passenger Van | 1985 - 1987 | L4 2.5L | RWD Automatic & Manual |
| Base | Standard Passenger Van | 1985 - 1987, 1997 - 2002 | V6 4.3L | RWD Automatic |
| Base | Standard Passenger Van | 1985 - 1987 | V6 4.3L | RWD Manual |
| CL | Extended Passenger Van | 1990 - 1995 | V6 4.3L | AWD/RWD Automatic |
| CL | Standard Passenger Van | 1990 - 1995 | V6 4.3L | AWD Automatic |
| CL | Standard Passenger Van | 1985 | L4 2.5L | RWD Automatic & Manual |
| CL | Standard Passenger Van | 1985 - 1995 | V6 4.3L | RWD Automatic |
| CL | Standard Passenger Van | 1985 - 1989 | V6 4.3L | RWD Manual |
| CS | Extended Passenger Van | 1990 - 1995 | V6 4.3L | AWD/RWD Automatic |
| CS | Standard Passenger Van | 1990 - 1995 | V6 4.3L | AWD Automatic |
| CS | Standard Passenger Van | 1985 | L4 2.5L | RWD Automatic & Manual |
| CS | Standard Passenger Van | 1985 - 1995 | V6 4.3L | RWD Automatic |
| CS | Standard Passenger Van | 1985 - 1989 | V6 4.3L | RWD Manual |
| LS | Extended Passenger Van | 1996 - 2002 | V6 4.3L | AWD/RWD Automatic |
| LS | Standard Passenger Van | 1996 - 2002 | V6 4.3L | AWD/RWD Automatic |
| LT | Extended Passenger Van | 1990 - 2002 | V6 4.3L | AWD/RWD Automatic |
| LT | Standard Passenger Van | 1990 - 2002 | V6 4.3L | AWD Automatic |
| LT | Standard Passenger Van | 1987 - 2002 | V6 4.3L | RWD Automatic |
| LT | Standard Passenger Van | 1987 - 1989 | V6 4.3L | RWD Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Aimco | 68170 |
| Autopart International | 1408-25099 |
| Autospecialty | AD8616 |
| Bendix | 140484 |
| Brembo | 23060 |
| Carquest | YH140484 |
| Delco-Remy | 177373 |
| Delco-Remy | 18B106 |
| Delco-Remy | 18B106A |
| Delta | 8844016 |
| EIS Brakes | D2034 |
| Euclid | E8378 |
| Formula Blue Hydraulic Brake Parts | E127-71-021 |
| Formula Blue Hydraulic Brake Parts | E12771021 |
| GWB | 87276 |
| IPI | 846 |
| Midas | BD1499 |
| Mighty Distributing System | 8949 |
| Neotek Drums and Rotors | 112034 |
| OEM Part Number | 14074862 |
| OEM Part Number | 15679733 |
| OEM Part Number | 18028419 |
| OEM Part Number | 19176903 |
| Pep Boys | 8949G |
| Qualitee International | 63 93 670 |
| Qualitee International | 6393670 |
| Raybestos Brakes | 2034 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X21677 |
| Wagner Brake | BD60792 |
Fits Years: 1985 1986 1987 1988 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002
Fits Models: Astro
