| Attribute | Value |
|---|---|
| ABS Equipped | No |
| Bolt Circle Diameter Mounting Flange | 116 |
| Bolt Circle Diameter Wheel Flange | 115 |
| Bolt Hole Size / Thread | M12x1.75 |
| Brake Pilot Diameter | 70.6 |
| Driven / Non Driven | Driven |
| Feature 1 | Premium Oe Technology - Vehicle Specific Fit-form And Performance |
| Feature 2 | Long Life Low Friction Bearing - Superfinished Precision Matched Bearing Raceway |
| Feature 3 | Water And Contamination Resistant - Advanced Multi-lip Seal Technology |
| Feature 4 | Zero Maintenance - Sealed For Life Design With Premium All Weather Grease |
| Flange Bolt Hole Quantity | 3 |
| Flange Diameter | 150 |
| Flange Offset | 76 |
| Generation | 3 |
| Hub Pilot Diameter | 91.25 |
| Number Of Splines | 33 |
| Wheel Pilot Diameter | 70.1 |
| Wheel Stud Quantity | 5 |
| Wheel Stud Size | M12x1.5 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| LS | SUV | 2005 | V6 3.4L | AWD/FWD Automatic |
| LT | SUV | 2005 | V6 3.4L | AWD/FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
Fits Years: 2005
Fits Models: Equinox
