| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Bearings Included | No |
| Center Hole Diameter | 118.1, 4.65 |
| Construction | Full Cast |
| Conventional Or Drum In Hat Type Rotor | Conventional |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 1.437, 36.5 |
| Harmonize Code | 8708.30.5030 |
| Misc. Holes | 2 |
| Mounting Bolt Hole Circle Diameter | 165.1, 6.5 |
| Mounting Bolt Hole Diameter | 0.635, 16.15 |
| Nominal Thickness | 1.5, 38.1 |
| Overall Height | 3.51, 89.15 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Extended Cargo Van | 2021 - 2022 | L4 2.8L DIESEL Turbo | RWD Automatic |
| Base | Extended Cargo Van | 2021 - 2025 | V6 4.3L | RWD Automatic |
| Base | Extended Cargo Van | 2021 - 2025 | V6 4.3L FLEX | RWD Automatic |
| Base | Extended Cargo Van | 2021 - 2025 | V8 6.6L | RWD Automatic |
| Base | Standard Cargo Van | 2021 - 2022 | L4 2.8L DIESEL Turbo | RWD Automatic |
| Base | Standard Cargo Van | 2021 - 2022 | L4 2.8L DIESEL Turbo | RWD Automatic |
| Base | Standard Cargo Van | 2021 - 2025 | V6 4.3L | RWD Automatic |
| Base | Standard Cargo Van | 2021 - 2023 | V6 4.3L | RWD Automatic |
| Base | Standard Cargo Van | 2021 - 2025 | V6 4.3L FLEX | RWD Automatic |
| Base | Standard Cargo Van | 2021 - 2023 | V6 4.3L FLEX | RWD Automatic |
| Base | Standard Cargo Van | 2021 - 2025 | V8 6.6L | RWD Automatic |
| Base | Standard Cargo Van | 2021 - 2023 | V8 6.6L | RWD Automatic |
| LS | Standard Passenger Van | 2021 - 2022 | L4 2.8L DIESEL Turbo | RWD Automatic |
| LS | Standard Passenger Van | 2021 - 2022 | L4 2.8L DIESEL Turbo | RWD Automatic |
| LS | Standard Passenger Van | 2021 - 2025 | V6 4.3L | RWD Automatic |
| LS | Standard Passenger Van | 2021 - 2023 | V6 4.3L | RWD Automatic |
| LS | Standard Passenger Van | 2021 - 2025 | V6 4.3L FLEX | RWD Automatic |
| LS | Standard Passenger Van | 2021 - 2023 | V6 4.3L FLEX | RWD Automatic |
| LS | Standard Passenger Van | 2021 - 2025 | V8 6.6L | RWD Automatic |
| LS | Standard Passenger Van | 2021 - 2023 | V8 6.6L | RWD Automatic |
| LT | Standard Passenger Van | 2021 - 2022 | L4 2.8L DIESEL Turbo | RWD Automatic |
| LT | Standard Passenger Van | 2021 - 2022 | L4 2.8L DIESEL Turbo | RWD Automatic |
| LT | Standard Passenger Van | 2021 - 2025 | V6 4.3L | RWD Automatic |
| LT | Standard Passenger Van | 2021 - 2023 | V6 4.3L | RWD Automatic |
| LT | Standard Passenger Van | 2021 - 2025 | V6 4.3L FLEX | RWD Automatic |
| LT | Standard Passenger Van | 2021 - 2023 | V6 4.3L FLEX | RWD Automatic |
| LT | Standard Passenger Van | 2021 - 2025 | V8 6.6L | RWD Automatic |
| LT | Standard Passenger Van | 2021 - 2023 | V8 6.6L | RWD Automatic |
We offer fast, reliable shipping on all orders:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
We want you to be 100% satisfied with your purchase. That's why we offer:
| Brand | Part Number |
|---|---|
| ACDelco | 177-880 |
| Advance Auto Parts | YH145316 |
| Advance Auto Parts | YH145316C |
| Advance Auto Parts | YH145316P |
| Autopartsource | 593245 |
| Autospecialty | AR8642 |
| Autoxtra | 80580000 |
| Autoxtra | AX5506 |
| Autoxtra | AX55072 |
| AutoZone | 55072DL |
| AutoZone | DL55072 |
| Bendix | 145316 |
| Bosch | RBR55072 |
| BrakeBest | 580000 |
| BrakeBest | 580000FZN |
| BrakeBest | 580000PER |
| BrakeBest | 580000R |
| BrakeBest | 580000RGS |
| BrakeBest | 81-126036 |
| Casting Numbers | 15733624C |
| Casting Numbers | 211359-C |
| Casting Numbers | 325559 |
| Centric Parts | 120.66042 |
| Centric Parts | 120.66059 |
| Centric Parts | 120.66059CRY |
| Centric Parts | 121.66059 |
| Centric Parts | 125.66059 |
| Centric Parts | 125.66059CRY |
| Centric Parts | 126.66059CSL |
| Centric Parts | 126.66059CSR |
| Centric Parts | 126.66059SL |
| Centric Parts | 126.66059SR |
| Centric Parts | 127.66059CL |
| Centric Parts | 127.66059CR |
| Centric Parts | 127.66059L |
| Centric Parts | 127.66059R |
| Centric Parts | 128.66059CL |
| Centric Parts | 128.66059CR |
| Centric Parts | 128.66059L |
| Centric Parts | 128.66059R |
| Centric Parts | 227.66059L |
| Centric Parts | 227.66059R |
| Centric Parts | 320.66059 |
| Centric Parts | 320.66059F |
| Dura Corp | BR55072 |
| Dura Corp | BR5507202 |
| General Motors | 15942198 |
| General Motors | 18060654 |
| Guardian | 52-126036 |
| Mighty Distributing System | 55072 |
| Pep Boys | 55072G |
| PowerStop | AR8655EVC |
| Promax | 14-55072 |
| Promax | 20-55072 |
| Qualitee International | 64-93-235 |
| Quality Brand | Q4153 |
| TruStar | 493235 |
| TruStar | R93235 |
| UAP | 2055072 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51473 |
| WABCO - Archived | PS126036 |
| Wagner Brake | BD126036 |
| Wagner Brake | BD126036E |
| Winhere | 6621030 |
| Winhere | YH2781 |
Fits Years: 2021 2022 2023 2024 2025
Fits Models: Express 2500
