Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.
| Attribute | Value |
|---|---|
| Connector Color | White |
| Connector Gender | Female |
| Fuel Filter Included | No |
| Fuel Sending Unit Included | Yes |
| Fuel Tank Pressure Sensor Included | Yes |
| Gasket Or Seal Included | Yes |
| Grade Type | Regular |
| Internal Or External Strainer | Internal |
| Lock Ring Included | No |
| Minimum Flow Rating | 20 |
| Minimum Pressure | 60.0 |
| Mounting Hardware Included | No |
| Negative Ground | Yes |
| Outlet Outside Diameter | 9.49 |
| Outlet Quantity | 1 |
| Pump Type | Electric |
| Regulator Included | No |
| Resistance Ohms Empty | 40.0 |
| Resistance Ohms Full | 250.0 |
| Strainer Included | Yes |
| Terminal Gender | Male |
| Terminal Quantity | 4 |
| Terminal Type | Blade |
| Top Mount Diameter | 103.0 |
| Wire Harness Included | Yes |
| Wire Quantity | 4 |
| Wiring Harness Length | 445.0 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Extended Cargo Van | 2002 | V8 5.7L BI-FUEL | RWD Automatic |
| Base | Extended Cargo Van | 2001 | V8 5.7L CNG | RWD Automatic |
| Base | Extended Cargo Van | 1998 - 2002 | V6 4.3L | RWD Automatic |
| Base | Extended Cargo Van | 1998 - 2002 | V8 5.0L | RWD Automatic |
| Base | Extended Cargo Van | 1998 - 2002 | V8 5.7L | RWD Automatic |
| Base | Extended Cargo Van | 1998 - 2002 | V8 6.5L DIESEL Turbo | RWD Automatic |
| Base | Extended Passenger Van | 2002 | V8 5.7L BI-FUEL | RWD Automatic |
| Base | Extended Passenger Van | 2001 | V8 5.7L CNG | RWD Automatic |
| Base | Extended Passenger Van | 1998 - 2002 | V6 4.3L | RWD Automatic |
| Base | Extended Passenger Van | 1998 - 2002 | V8 5.0L | RWD Automatic |
| Base | Extended Passenger Van | 1998 - 2002 | V8 5.7L | RWD Automatic |
| Base | Extended Passenger Van | 1998 - 2002 | V8 6.5L DIESEL Turbo | RWD Automatic |
| Base | Standard Cargo Van | 2002 | V8 5.7L BI-FUEL | RWD Automatic |
| Base | Standard Cargo Van | 2001 | V8 5.7L CNG | RWD Automatic |
| Base | Standard Cargo Van | 1998 - 2002 | V6 4.3L | RWD Automatic |
| Base | Standard Cargo Van | 1998 - 2002 | V8 5.0L | RWD Automatic |
| Base | Standard Cargo Van | 1998 - 2002 | V8 5.7L | RWD Automatic |
| Base | Standard Cargo Van | 1998 - 2002 | V8 6.5L DIESEL Turbo | RWD Automatic |
| Base | Standard Passenger Van | 2002 | V8 5.7L BI-FUEL | RWD Automatic |
| Base | Standard Passenger Van | 2001 | V8 5.7L CNG | RWD Automatic |
| Base | Standard Passenger Van | 1998 - 2002 | V6 4.3L | RWD Automatic |
| Base | Standard Passenger Van | 1998 - 2002 | V8 5.0L | RWD Automatic |
| Base | Standard Passenger Van | 1998 - 2002 | V8 5.7L | RWD Automatic |
| Base | Standard Passenger Van | 1998 - 2002 | V8 6.5L DIESEL Turbo | RWD Automatic |
| LS | Extended Passenger Van | 2002 | V8 5.7L BI-FUEL | RWD Automatic |
| LS | Extended Passenger Van | 2001 | V8 5.7L CNG | RWD Automatic |
| LS | Extended Passenger Van | 1999 - 2002 | V6 4.3L | RWD Automatic |
| LS | Extended Passenger Van | 1998 - 2002 | V8 5.0L | RWD Automatic |
| LS | Extended Passenger Van | 1998 - 2002 | V8 5.7L | RWD Automatic |
| LS | Extended Passenger Van | 1998 - 2002 | V8 6.5L DIESEL Turbo | RWD Automatic |
| LS | Standard Passenger Van | 2002 | V8 5.7L BI-FUEL | RWD Automatic |
| LS | Standard Passenger Van | 2001 | V8 5.7L CNG | RWD Automatic |
| LS | Standard Passenger Van | 1999 - 2002 | V6 4.3L | RWD Automatic |
| LS | Standard Passenger Van | 1998 - 2002 | V8 5.0L | RWD Automatic |
| LS | Standard Passenger Van | 1998 - 2002 | V8 5.7L | RWD Automatic |
| LS | Standard Passenger Van | 1998 - 2002 | V8 6.5L DIESEL Turbo | RWD Automatic |
We offer fast, reliable shipping on all orders:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
We want you to be 100% satisfied with your purchase. That's why we offer:
| Brand | Part Number |
|---|---|
| 1-800-Radiator | 2920081 |
| ACDelco | MU1115 |
| ACDelco | MU159 |
| Canadian Tire | 237846 |
| General Motors | 25314347 |
| Precise | 402-P3971M |
| Sparta | PN3009 |
| Spectra Premium | SP457M |
| TruGrade | B11111500TG |
| TYC | 150017 |
Fits Years: 1998 1999 2000 2001 2002
Fits Models: Express 2500
In operation since 2007. Trusted by over a million DIYers, mechanics, and body shops across all 50 states.
If it doesn't fit, we make it right. No gimmicks, no fine print.
Most retailers stop at 30 days. We give you a full four months to install, test, and return for a 100% refund — return shipping on us.
Brand-new aftermarket parts from trusted suppliers — built to original-equipment specifications so they fit and function like the factory unit, at a fraction of the price.
