2006 - 2024 Chevrolet Trailblazer Tire Pressure Monitoring System (TPMS) Programmabl (Schrader)

$45.08
Save up to 80% vs List Price!

ℹ️ Product Notes

Use 33500 if 33600 is not available Screw torque = 11.5 in-lbs; Valve core torque = 3.5 in-lbs, 0.4Nm Attachment Type: Clamp-in Angle Type: Fixed Angled Stem: Fixed angle Silver Stem

Schrader EZ-sensor is a programmable sensor that combines 314.9, 315, and 433 MHz frequencies into one SKU. This multi-frequency solution has market-leading vehicle coverage and is compatible with most independent TPMS programming and diagnostics tools. EZ-sensor performs identically to OE replacement TPMS sensors and helps reduce the overall cost of service and optimize inventory levels. EZ-sensor can be interchanged with rubber snap-in valve stems or fixed angle aluminum clamp-in stems, available in silver and matte black. This sensor is not a DIY product and requires appropriate skills, knowledge, and equipment for service. Each EZ-sensor must be programmed before installation and needs a compatible TPMS programming tool.
Brand: Schrader
Condition: New
See Other Chevrolet Trailblazer Tire Pressure Monitoring System (TPMS) Programmabls
🤝
100% Money-Back Guarantee
↩️
120-Day Returns
🏅
Insurance-Grade Quality

🛡️ Lifetime Warranty Included

This part comes with our industry-leading lifetime warranty. Shop with confidence!

SKU #
9DF7772
  • Direct Fit for 2006 - 2024 Chevrolet Trailblazer
  • New Condition
  • Schrader Quality
  • Easy Installation - No Modifications
Wrenchy the Robot

Meet Wrenchy - The Amazing Parts Assistant!Meet Wrenchy
The Amazing Assistant!

Let Wrenchy help you confirm if this is the right part.

Ask Wrenchy -
Type or Speak! 🎤

Product Specifications


Detailed specifications and attributes for this part:

Attribute Value
Activation Type Not Programmed, Programmable
Attachment Type Clamp-in
California Prop 65 Warning Label (Text) Warning: This Product Can Expose You To Chemicals Including Lead, Which Is Known To The State Of California To Cause Cancer And Birth Defects And Other Reproductive Harm. For More Information, Go To Www.p65warnings.ca.gov
Manufacturer Warranty 2 Years
Material Aluminum
Monitor Type Direct
Mounting Hardware Included Yes
Power Source Battery
Real Time Pressure Signal Transmission Yes
Valve Color Silver

Vehicle Fitment Guide

This part fits the following vehicles:

Chevrolet
Trailblazer 2006-2024 (tapclick to expand)(tapclick to hide)
Swipe left/right to see more info
SubmodelSUB-
MODEL		 Body Style Years Engine Attributes
A SUV 2006 - 2007 L6 4.2L RWD Automatic
ACTIV SUV 2021 - 2024 L3 1.3L Turbo AWD/FWD Automatic & Automatic CVT
B SUV 2006 - 2007 L6 4.2L RWD Automatic
B SUV 2006 L6 4.2L 4WD Automatic
Base SUV 2008 L6 4.2L 4WD Automatic
Base SUV 2008 V8 5.3L RWD/4WD Automatic
Base SUV 2006 - 2008 L6 4.2L RWD Automatic
L SUV 2021 - 2022 L3 1.2L Turbo FWD Automatic CVT
LS SUV 2021 - 2024 L3 1.2L Turbo AWD/FWD Automatic & Automatic CVT
LS SUV 2021 - 2024 L3 1.3L Turbo AWD/FWD Automatic & Automatic CVT
LS SUV 2006 - 2007 L6 4.2L RWD/4WD Automatic
LS SUV 2006 - 2007 V8 5.3L RWD/4WD Automatic
LT SUV 2021 - 2024 L3 1.2L Turbo AWD/FWD Automatic & Automatic CVT
LT SUV 2021 - 2024 L3 1.3L Turbo AWD/FWD Automatic & Automatic CVT
LT SUV 2006 - 2009 L6 4.2L RWD/4WD Automatic
LT SUV 2006 - 2008 V8 5.3L RWD/4WD Automatic
RS SUV 2021 - 2024 L3 1.3L Turbo AWD/FWD Automatic & Automatic CVT
SS SUV 2006 - 2009 V8 6.0L AWD/RWD Automatic

⚠️ Important: Please verify your vehicle's year, make, model, and specifications before ordering. If you're unsure about fitment, contact our customer service team for assistance.

Policies

Shipping Information

We offer fast, reliable shipping on all orders:

  • Ships to all countries via US Postal Service Priority Mail.
  • Most orders ship within 1 business day.
  • Delivery time: 1-4 business days after shipment.
  • International shipping available, including APO/FPO addresses.
  • Tracking information provided for all shipments.
  • Additional handling fees may apply for oversized/overweight packages.

Return Policy

We want you to be 100% satisfied with your purchase. That's why we offer:

  • 120-Day Returns - Return any part within 120 days from date of receipt.
  • Must obtain RMA (Return Merchandise Authorization) number before returning.
  • Parts must be in original condition, uninstalled, unaltered, and in original packaging.
  • Important: Electrical parts are not returnable if unsealed.
  • Please inspect parts upon arrival and notify us within 5 days of receiving incorrect or damaged parts.
  • Refunds processed after warehouse receives return and credited to original payment method.

Warranty

This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.

Warranty does NOT cover:

  • Shipping costs or labor expenses.
  • Installation errors.
  • Parts used for racing.
  • Commercial vehicle parts.

More Information


Schrader EZ-sensor is a programmable sensor that combines 314.9, 315, and 433 MHz frequencies into one SKU. This multi-frequency solution has market-leading vehicle coverage and is compatible with most independent TPMS programming and diagnostics tools. EZ-sensor performs identically to OE replacement TPMS sensors and helps reduce the overall cost of service and optimize inventory levels. EZ-sensor can be interchanged with rubber snap-in valve stems or fixed angle aluminum clamp-in stems, available in silver and matte black. This sensor is not a DIY product and requires appropriate skills, knowledge, and equipment for service. Each EZ-sensor must be programmed before installation and needs a compatible TPMS programming tool.

Fits Years: 2006 2007 2008 2009 2021 2022 2023 2024

Fits Models: Trailblazer
