Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.
| Attribute | Value |
|---|---|
| 4181 ABS Tone Ring Included | No |
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.80, 70.50 |
| Construction | Composite, Full Cast |
| Discard Thickness | 1.21, 30.7, 30.70 |
| Grade Type | Premium |
| Material | Gray Cast Iron |
| Nominal Thickness | 32, 32.00 |
| Overall Height | 2.05, 52, 52.00 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| Weight | 6.8 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Mini Passenger Van | 1997 - 2004 | V6 3.4L | FWD Automatic |
| Base | Mini Passenger Van | 1997 - 1999 | V6 3.4L | FWD Automatic |
| LS | Mini Passenger Van | 2002 - 2004 | V6 3.4L | AWD Automatic |
| LS | Mini Passenger Van | 1997 - 2005 | V6 3.4L | FWD Automatic |
| LS | Mini Passenger Van | 1997 - 1999 | V6 3.4L | FWD Automatic |
| LT | Mini Passenger Van | 2002 - 2004 | V6 3.4L | AWD Automatic |
| LT | Mini Passenger Van | 2000 - 2005 | V6 3.4L | FWD Automatic |
| Plus | Mini Passenger Van | 2000 - 2005 | V6 3.4L | FWD Automatic |
| Value | Mini Passenger Van | 2000 - 2003 | V6 3.4L | FWD Automatic |
| Warner Bros. | Mini Passenger Van | 2002 - 2003 | V6 3.4L | AWD Automatic |
| Warner Bros. | Mini Passenger Van | 2000 - 2003 | V6 3.4L | FWD Automatic |
We offer fast, reliable shipping on all orders:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
We want you to be 100% satisfied with your purchase. That's why we offer:
| Brand | Part Number |
|---|---|
| Aimco | 55036 |
| ATE | 24013201101 |
| ATE | CW32110 |
| Bosch | 0986478486 |
| Bosch | 0986UB0525 |
| Brembo | 27007 |
| Buick | 18021359 |
| Buick | 18060233 |
| Centric Parts | 120.62057 |
| Centric Parts | 121.62057 |
| Centric Parts | 125.62057 |
| Centric Parts | 320.62057 |
| Centric Parts | 32062056F |
| DuraGo | BR55036 |
| DuraGo | BR5503601 |
| DuraGo | BR5503602 |
| Ferodo | DDF1030 |
| GMC | 18038816 |
| GMC | 19175049 |
| GMC | 569057 |
| GMC | 90542181 |
| NAPA Proformer | PFR 24886631 |
| Raybestos Brakes | 56631 |
| Raybestos Brakes | 56631FZN |
| Raybestos Brakes | 56631R |
| Textar | 92091500 |
| TRW | DF4041 |
| Wagner Brake | BD125507 |
| Wagner Brake | BD125507E |
| Winhere | 4420018 |
| Zimmermann | 430.1479.20 |
| Zimmermann | 430147920 |
Fits Years: 1997 1998 1999 2000 2001 2002 2003 2004 2005
Fits Models: Venture
