| Attribute | Value |
|---|---|
| Axis 1 Length | 447 |
| Axis 2 Length | 270 |
| Axis 3 Length | 473 |
| Axis 4 Length | 268 |
| Branch Quantity | 4 |
| Burst Pressure | 75 |
| Centerline Length | 1458 |
| Clamps Included | Oui, Sí, Yes |
| Color | Black, Natural, Negro |
| Contains Spring | No, Non |
| Contenidos Del Paquete | Conjunto De Manguera Del Calentador |
| Coolant Hose Heat Shield Included | No, Non |
| Coolant Hose Type | Branched, Ramificado |
| Diámetro Exterior (in) Del Extremo De La Manguera (4) | 35.75 Mm |
| Diámetro Exterior Del Extremo De La Manguera (1) (in) | 26mm |
| Diámetro Exterior Del Extremo De La Manguera (2) (in) | 27.2 Mm |
| Diámetro Exterior Del Extremo De La Manguera (3) (in) | 27.2 Mm |
| Diámetro Interior (in) Del Extremo De La Manguera (4) | 28.5 Mm |
| End 1 Attachment Type | Hose, Manguera |
| End 1 Inside Diameter | 18.5 |
| End 2 Attachment Type | Desconexión Rápida, Quick Disconnect |
| End 2 Inside Diameter | 22.2 |
| End 3 Attachment Type | Quick Disconnect |
| End 3 Inside Diameter | 22.2 |
| End 4 Attachment Type | Quick Disconnect |
| End 4 Inside Diameter | 28.5 |
| Grade Type | Regular |
| Hose End (1) Outside Diameter (In) | 26 Mm |
| Hose End (2) Outside Diameter (In) | 27.2 Mm |
| Hose End (3) Outside Diameter (In) | 27.2 Mm |
| Hose End (4) Inside Diameter (In) | 28.5 Mm |
| Hose End (4) Outside Diameter (In) | 35.75 Mm |
| Hose Shape | Ensamble Moldeado, Molded Assembly |
| Material | Epdm, Metal |
| Maximum Bend Angle | 120 |
| Maximum Working Pressure | 100 |
| Protective Sleeve Attached | No, Non |
| Thermostatically Controlled | No, Non |
| Tipo De Fijación Del Extremo 3 | Desconexión Rápida |
| Tipo De Fijación Del Extremo 4 | Desconexión Rápida |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| AWD Launch Edition | Mini Passenger Van | 2020 | V6 3.6L | AWD Automatic |
| AWD Launch Edition | Mini Passenger Van | 2020 | V6 3.6L FLEX | AWD Automatic |
| Hybrid Limited | Mini Passenger Van | 2018 - 2020 | V6 3.6L PLUG-IN HYBRID EV-GAS (PHEV) | FWD Automatic |
| Hybrid Platinum | Mini Passenger Van | 2017 | V6 3.6L PLUG-IN HYBRID EV-GAS (PHEV) | FWD Automatic |
| Hybrid Premium | Mini Passenger Van | 2017 | V6 3.6L PLUG-IN HYBRID EV-GAS (PHEV) | FWD Automatic |
| Hybrid Touring | Mini Passenger Van | 2017, 2020 | V6 3.6L PLUG-IN HYBRID EV-GAS (PHEV) | FWD Automatic |
| Hybrid Touring L | Mini Passenger Van | 2018 - 2020 | V6 3.6L PLUG-IN HYBRID EV-GAS (PHEV) | FWD Automatic |
| Hybrid Touring Plus | Mini Passenger Van | 2018 - 2019 | V6 3.6L PLUG-IN HYBRID EV-GAS (PHEV) | FWD Automatic |
| L | Mini Passenger Van | 2018 - 2020 | V6 3.6L | FWD Automatic |
| L | Mini Passenger Van | 2018 - 2020 | V6 3.6L FLEX | FWD Automatic |
| LX | Mini Passenger Van | 2017 - 2020 | V6 3.6L | FWD Automatic |
| LX | Mini Passenger Van | 2017 - 2020 | V6 3.6L FLEX | FWD Automatic |
| Limited | Mini Passenger Van | 2017 - 2020 | V6 3.6L | FWD Automatic |
| Limited | Mini Passenger Van | 2017 - 2020 | V6 3.6L FLEX | FWD Automatic |
| Limited Platinum | Mini Passenger Van | 2018 - 2020 | V6 3.6L | FWD Automatic |
| Touring | Mini Passenger Van | 2017 - 2020 | V6 3.6L | FWD Automatic |
| Touring | Mini Passenger Van | 2017 - 2020 | V6 3.6L FLEX | FWD Automatic |
| Touring L | Mini Passenger Van | 2017 - 2020 | V6 3.6L | FWD Automatic |
| Touring L | Mini Passenger Van | 2017 - 2020 | V6 3.6L FLEX | FWD Automatic |
| Touring L Plus | Mini Passenger Van | 2017 - 2020 | V6 3.6L | FWD Automatic |
| Touring L Plus | Mini Passenger Van | 2017 - 2020 | V6 3.6L FLEX | FWD Automatic |
| Touring Plus | Mini Passenger Van | 2018 - 2019 | V6 3.6L | FWD Automatic |
| Touring Plus | Mini Passenger Van | 2018 - 2019 | V6 3.6L FLEX | FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Chrysler | 68217334AB |
| Chrysler | 68217334AC |
Fits Years: 2017 2018 2019 2020
Fits Models: Pacifica
