| Attribute | Value |
|---|---|
| Adjustable | No |
| Bearing Material | Plastic |
| Color | Gray |
| Cone Outside Diameter | 0.705, 17.90 |
| Dust Boot Included | Yes |
| Dust Boot Material | Rubber |
| End 1 Thread Diameter | 0.563, 14.29 |
| End 1 Thread Direction | Clockwise (right) |
| End 1 Threads Per Inch | 18 |
| End 2 Thread Diameter | 0.687, 17.46 |
| End 2 Thread Direction | Counterclockwise (left) |
| End 2 Threads Per Inch | 16 |
| Grade Type | Standard Replacement |
| Length Stud Center To End | 111.30, 4.382 |
| Mounting Hardware Included | Yes |
| Position(s) | Left, Outer. For The Position Specific To Your Vehicle, Refer To The Applications. |
| Pre Greased | Yes |
| Shank Length | 0.705, 17.90 |
| Stud Type | Threaded |
| Tie Rod Material | Steel |
| Tube Diameter | 0.688, 17.46 |
| Type | Bent |
| Weight | 1.08 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Standard Cargo Van | 1976 - 1978 | L6 3.7L | RWD Automatic & Manual |
| Base | Standard Cargo Van | 1976 - 1978 | V8 5.2L | RWD Automatic & Manual |
| Base | Standard Cargo Van | 1976 - 1978 | V8 5.9L | RWD Automatic & Manual |
| Base | Standard Passenger Van | 1976 - 1978 | L6 3.7L | RWD Automatic & Manual |
| Base | Standard Passenger Van | 1976 - 1978 | V8 5.2L | RWD Automatic & Manual |
| Base | Standard Passenger Van | 1976 - 1978 | V8 5.9L | RWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
Fits Years: 1976 1977 1978
Fits Models: B100
