| Attribute | Value |
|---|---|
| Belt Type | V-belt |
| Belt Width IN | 0.44 |
| Clutch Included | Included |
| Coil Clock | 1 Wire Lead |
| Electronic Control Valve | No |
| Groove | 1 |
| Model | Fx105 |
| Mount Distance IN | 3.000 |
| Mounting Hardware? | Not Included |
| New Or Reman | Remanufactured |
| O Ring A Number/Desc | 24608 / Green O-ring |
| O Ring A Quantity | 1 |
| O Ring B Number/Desc | 24610 / Green O-ring |
| O Ring B Quantity | 1 |
| Oil Type | Pag 46 |
| Pulley Diameter IN | 4.36 |
| Pulley Diameter MM | 111 |
| Refrigerant Type | R134a |
| Suction Port Type | Pad Mount |
| Switch / Sensor Desc | Sensor Port |
| Switch Type | Heat Switch |
| Type | Mitsubishi |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 100 DL | Hatchback | 1989 - 1991 | L4 1.5L | FWD U/K |
| 100 DL | Hatchback | 1989 | L4 1.6L Turbo | FWD U/K |
| 100 DL | Sedan | 1989 - 1991 | L4 1.5L | FWD U/K |
| 100 DL | Sedan | 1989 | L4 1.6L Turbo | FWD U/K |
| 100 E | Hatchback | 1989 - 1992 | L4 1.5L | FWD U/K |
| 100 E | Sedan | 1989 - 1992 | L4 1.5L | FWD U/K |
| 100 LX | Hatchback | 1989 - 1990 | L4 1.5L | FWD U/K |
| 100 LX | Hatchback | 1989 - 1990 | L4 1.6L Turbo | FWD U/K |
| 100 LX | Sedan | 1989 - 1990 | L4 1.5L | FWD U/K |
| 100 LX | Sedan | 1989 - 1990 | L4 1.6L Turbo | FWD U/K |
| 200 DL | Hatchback | 1989 - 1990 | L4 1.5L | FWD U/K |
| 200 DL | Sedan | 1989 - 1990 | L4 1.5L | FWD U/K |
| 200 E | Hatchback | 1989 - 1990, 1992 | L4 1.5L | FWD U/K |
| 200 E | Sedan | 1989 - 1990 | L4 1.5L | FWD U/K |
| 200 GT | Hatchback | 1991 - 1992 | L4 1.5L | FWD U/K |
| 200 LX | Hatchback | 1989 | L4 1.5L | FWD U/K |
| 200 LX | Hatchback | 1989 | L4 1.6L | FWD U/K |
| 200 LX | Sedan | 1989 | L4 1.5L | FWD U/K |
| 200 LX | Sedan | 1989 | L4 1.6L | FWD U/K |
| 4x4 | Wagon | 1993 | L4 2.4L | AWD U/K |
| Base | Hatchback | 1991 - 1992 | L4 1.5L | FWD Automatic |
| Base | Hatchback | 1989 - 1992 | L4 1.5L | FWD Manual |
| Base | Sedan | 1993 | L4 1.5L | FWD Automatic & Manual |
| Base | Sedan | 1993 | L4 1.5L | FWD Automatic & Manual |
| Base | Sedan | 1993 | L4 1.8L | FWD Automatic & Manual |
| Base | Sedan | 1993 | L4 1.8L | FWD Automatic & Manual |
| Base | Sedan | 1993 | L4 2.4L | FWD Automatic & Manual |
| DL | Wagon | 1989 - 1990 | L4 1.5L | FWD/4WD Automatic & Manual |
| DL | Wagon | 1989 - 1990 | L4 1.8L | FWD/4WD Automatic & Manual |
| E | Hatchback | 1989 | L4 1.5L | FWD Automatic & Manual |
| GL | Hatchback | 1990 - 1992 | L4 1.5L | FWD Automatic & Manual |
| GL | Sedan | 1993 | L4 1.5L | FWD Automatic & Manual |
| GL | Sedan | 1993 | L4 1.5L | FWD Automatic & Manual |
| GL | Sedan | 1993 | L4 1.8L | FWD Automatic & Manual |
| GL | Sedan | 1993 | L4 1.8L | FWD Automatic & Manual |
| GT | Hatchback | 1990 | L4 1.6L | FWD Automatic & Manual |
| GT | Hatchback | 1989 - 1990 | L4 1.5L | FWD Automatic & Manual |
| GT | Hatchback | 1989 | L4 1.6L Turbo | FWD Automatic & Manual |
| SE | Hatchback | 1993 | L4 2.4L | FWD U/K |
| SE | Hatchback | 1992 | L4 1.8L | FWD U/K |
| Vista | Wagon | 1989 - 1991 | L4 2.0L | FWD/4WD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Gilmore Products | 57306 |
| Gilmore Products | AC1206006 |
| Global Parts Distributors LLC | 7511928 |
| Visteon | 000426 |
| Visteon | 000430 |
Fits Years: 1989 1990 1991 1992 1993
Fits Models: Colt
