| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.84, 72.15 |
| Conventional Or Drum In Hat Type Rotor | Drum-in-hat |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 0.433, 11 |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 114.3, 4.5 |
| Mounting Bolt Hole Diameter | 0.546, 13.85 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.472 |
| Overall Height | 2.2, 55.9 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Hybrid | SUV | 2009 - 2010 | L4 2.5L FULL HYBRID EV-GAS (FHEV) | FWD/4WD Automatic CVT |
| Hybrid | SUV | 2005 - 2008 | L4 2.3L FULL HYBRID EV-GAS (FHEV) | FWD/4WD Automatic CVT |
| Limited | SUV | 2010 | V6 3.0L FLEX | FWD/4WD Automatic |
| Limited | SUV | 2009 - 2010 | L4 2.5L | FWD/4WD Automatic |
| Limited | SUV | 2005 - 2010 | V6 3.0L | FWD Automatic |
| Limited | SUV | 2005 - 2009 | V6 3.0L | 4WD Automatic |
| Limited Hybrid | SUV | 2009 - 2010 | L4 2.5L FULL HYBRID EV-GAS (FHEV) | FWD/4WD Automatic CVT |
| XLS | SUV | 2009 - 2010 | L4 2.5L | FWD/4WD Automatic & Manual |
| XLS | SUV | 2008 - 2010 | L4 2.5L | FWD Automatic |
| XLS | SUV | 2006 - 2007 | L4 2.3L | AWD Automatic |
| XLS | SUV | 2006 - 2007 | V6 3.0L | AWD Automatic |
| XLS | SUV | 2005 - 2008 | L4 2.3L | FWD/4WD Automatic & Manual |
| XLS | SUV | 2005 - 2010 | V6 3.0L | FWD Automatic |
| XLS | SUV | 2005 | V6 3.0L | FWD/4WD Automatic & Manual |
| XLT | SUV | 2010 | V6 3.0L FLEX | FWD/4WD Automatic |
| XLT | SUV | 2009 - 2010 | L4 2.5L | FWD/4WD Automatic |
| XLT | SUV | 2005 - 2008 | L4 2.3L | FWD/4WD Automatic |
| XLT | SUV | 2005 - 2010 | V6 3.0L | FWD Automatic |
| XLT | SUV | 2005 - 2009 | V6 3.0L | 4WD Automatic |
| XLT Deportivo | SUV | 2005 - 2007 | V6 3.0L | AWD/FWD Automatic |
| XLT No Boundaries | SUV | 2005 | L4 2.3L | FWD/4WD Automatic |
| XLT No Boundaries | SUV | 2005 | V6 3.0L | FWD/4WD Automatic |
| XLT Sport | SUV | 2005 | V6 3.0L | FWD/4WD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Advance Auto Parts | YH145566 |
| Advance Auto Parts | YH145566C |
| Advance Auto Parts | YH145566P |
| Autopartsource | 492615 |
| Autoxtra | 80680271 |
| Autoxtra | AX54122 |
| AutoZone | 54122DG |
| Bendix | 145566 |
| Bosch | 20010434 |
| BrakeBest | 680271 |
| BrakeBest | 680271FZN |
| BrakeBest | 680271R |
| BrakeBest | 680271RGS |
| Brembo | 27402 |
| Casting Numbers | 211660-C |
| Casting Numbers | 326212 |
| Casting Numbers | 5L842C026 |
| Centric Parts | 120.65108 |
| Centric Parts | 121.65108 |
| Centric Parts | 126.65108CSL |
| Centric Parts | 126.65108CSR |
| Centric Parts | 126.65108SL |
| Centric Parts | 126.65108SR |
| Centric Parts | 128.65108CL |
| Centric Parts | 128.65108CR |
| Centric Parts | 128.65108L |
| Centric Parts | 128.65108R |
| Centric Parts | 320.65108 |
| Centric Parts | 321.65108 |
| Dura Corp | BR54122 |
| Dura Corp | BR5412202 |
| Mazda | EF9126251 |
| Mazda | EF9126251A |
| Mazda | EFTT26251 |
| Mighty Distributing System | 54122 |
| Motorcraft | BRR132 |
| Motorcraft | NBRR101 |
| NAPA BRAKES | TSR9561 |
| Parts Master | 126120 |
| PowerStop | AR85104EVC |
| Promax | 14-54122 |
| Quality Brand | Q4187 |
| Ultra Brake | 54217 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51672 |
| WABCO - Archived | PS126120 |
| Wagner Brake | BD126120 |
| Wagner Brake | BD126120E |
| Winhere | 661644 |
Fits Years: 2005 2006 2007 2008 2009 2010
Fits Models: Escape
