| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.504, 63.6 |
| Conventional Or Drum In Hat Type Rotor | Conventional |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 0.91, 23.1 |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 107.95, 4.25 |
| Mounting Bolt Hole Diameter | 0.54, 13.7 |
| Nominal Thickness | 0.98, 24.9 |
| Overall Height | 1.917, 48.7 |
| Salability Restrictions | No |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| S | SUV | 2013 - 2019 | L4 2.5L | FWD Automatic |
| S Plus | SUV | 2013 - 2014, 2017 - 2019 | L4 2.5L | FWD Automatic |
| SE | SUV | 2017 - 2019 | L4 1.5L Turbo | AWD/FWD Automatic |
| SE | SUV | 2015 - 2016 | L4 2.5L | AWD Automatic |
| SE | SUV | 2013 - 2016 | L4 1.6L Turbo | AWD/FWD Automatic |
| SE | SUV | 2013 - 2019 | L4 2.0L Turbo | AWD/FWD Automatic |
| SE | SUV | 2013 - 2016 | L4 2.5L | FWD Automatic |
| SE Plus | SUV | 2013 - 2014 | L4 2.5L | FWD Automatic |
| SEL | SUV | 2018 - 2019 | L4 1.5L Turbo | AWD/FWD Automatic |
| SEL | SUV | 2013 | L4 1.6L Turbo | AWD/FWD Automatic |
| SEL | SUV | 2013, 2018 - 2019 | L4 2.0L Turbo | AWD/FWD Automatic |
| SEL | SUV | 2013 | L4 2.5L | FWD Automatic |
| Titanium | SUV | 2017 | L4 1.5L Turbo | AWD/FWD Automatic |
| Titanium | SUV | 2015 - 2017 | L4 2.5L | FWD Automatic |
| Titanium | SUV | 2014 - 2016 | L4 1.6L Turbo | AWD/FWD Automatic |
| Titanium | SUV | 2013 - 2019 | L4 2.0L Turbo | AWD/FWD Automatic |
| Trend | SUV | 2015 - 2016 | L4 2.0L Turbo | FWD Automatic |
| Trend | SUV | 2015 - 2016 | L4 2.5L | FWD Automatic |
| Trend Advance | SUV | 2017 - 2019 | L4 2.0L Turbo | FWD Automatic |
| Trend Advance | SUV | 2017 - 2019 | L4 2.5L | FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Advance Auto Parts | YH200353 |
| Advance Auto Parts | YH200353C |
| Advance Auto Parts | YH200353P |
| Autopartsource | 421350 |
| Autoxtra | AX900704 |
| AutoZone | 79901 |
| AutoZone | 79901DG |
| AutoZone | 79901DL |
| Bendix | PRT6221 |
| Bosch | 20011540 |
| Bosch | 52011380 |
| Bosch | 52011562 |
| BrakeBest | 980601 |
| BrakeBest | 980601FZN |
| BrakeBest | 980601R |
| BrakeBest | 980601RGS |
| Brembo | 09.9468.11 |
| Brembo | 25662 |
| Centric Parts | 120.39037 |
| Centric Parts | 121.39037 |
| Centric Parts | 125.39037 |
| Centric Parts | 125.39037CRY |
| Centric Parts | 126.39037CSL |
| Centric Parts | 126.39037CSR |
| Centric Parts | 126.39037SL |
| Centric Parts | 126.39037SR |
| Centric Parts | 127.39037CL |
| Centric Parts | 127.39037CR |
| Centric Parts | 127.39037L |
| Centric Parts | 127.39037R |
| Centric Parts | 128.39037CL |
| Centric Parts | 128.39037CR |
| Centric Parts | 128.39037L |
| Centric Parts | 128.39037R |
| Centric Parts | 320.39037 |
| Dura Corp | BR34364 |
| Dura Corp | BR900704 |
| Motorcraft | NBRR19 |
| NAPA BRAKES | TSR9353 |
| NAPA BRAKES | TSR9380 |
| Newtek Automotive USA | 34364 |
| Parts Master | 900704 |
| PowerStop | EBR896EVC |
| Promax | 14-34364 |
| Qualis | 45438 |
| Qualis | 45440 |
| Qualis | 45608 |
| TRW | 4424 |
| TRW | DF4109S |
| TRW | DF4424S |
| Ultra Brake | VO-934 |
| Volvo | 274510 |
| Volvo | 31262719 |
| Volvo | 312627190 |
| Volvo | 31362412 |
| Volvo | 313624120 |
| Volvo | 31400817 |
| Volvo | 314008170 |
| Volvo | 31400937 |
| Volvo | 314009370 |
| Volvo | 31400941 |
| Volvo | 31471749 |
| Volvo | 314717490 |
| Volvo | 31471819 |
| Volvo | 314718190 |
| Volvo | 31471834 |
| Volvo | 314718340 |
| WABCO - Archived | PS34364 |
| Wagner Brake | BD126447 |
| Wagner Brake | BD126447E |
| Wagner Brake | BD180519 |
| Wagner Brake | BD180519E |
| Winhere | 662960 |
Fits Years: 2013 2014 2015 2016 2017 2018 2019
Fits Models: Escape
