| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.68, 68.05 |
| Conventional Or Drum In Hat Type Rotor | Conventional |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 1.122, 28.5 |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 209.3, 8.24 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 114.3, 4.5 |
| Mounting Bolt Hole Diameter | 0.56, 14.2 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.183, 30.05 |
| Overall Height | 1.852, 47.05 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2016 - 2019 | L4 2.3L Turbo | AWD/FWD Automatic |
| Base | SUV | 2012 - 2015 | L4 2.0L Turbo | AWD/FWD Automatic |
| Base | SUV | 2011 - 2019 | V6 3.5L | AWD/FWD Automatic |
| Limited | SUV | 2017 | V6 3.5L | 4WD Automatic |
| Limited | SUV | 2016 - 2019 | L4 2.3L Turbo | AWD/FWD Automatic |
| Limited | SUV | 2012 - 2015 | L4 2.0L Turbo | AWD/FWD Automatic |
| Limited | SUV | 2011 - 2019 | V6 3.5L | AWD/FWD Automatic |
| Platinum | SUV | 2018 - 2019 | V6 3.5L Turbo | 4WD Automatic |
| Platinum | SUV | 2016 - 2019 | V6 3.5L Turbo | AWD Automatic |
| Sport | SUV | 2017 - 2019 | V6 3.5L Turbo | 4WD Automatic |
| Sport | SUV | 2015 | V6 3.5L Turbo | FWD Automatic |
| Sport | SUV | 2013 - 2019 | V6 3.5L Turbo | AWD Automatic |
| XLT | SUV | 2016 - 2019 | L4 2.3L Turbo | AWD/FWD Automatic |
| XLT | SUV | 2012 - 2015 | L4 2.0L Turbo | AWD/FWD Automatic |
| XLT | SUV | 2011 - 2019 | V6 3.5L | AWD/FWD Automatic |
| XLT Base | SUV | 2011 - 2013 | V6 3.5L | FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Advance Auto Parts | G09526SD |
| Advance Auto Parts | N1000393056WBR |
| Advance Auto Parts | YH322455 |
| Advance Auto Parts | YH322455C |
| Advance Auto Parts | YH322455P |
| Autopartsource | 592123 |
| Bendix | PRT6124 |
| Bosch | 20011505 |
| Bosch | 20011511 |
| BrakeBest | 621261RGS |
| BrakeBest | 680758 |
| BrakeBest | 680758FZN |
| BrakeBest | 680758PER |
| BrakeBest | 680758R |
| Centric Parts | 120.61102 |
| Centric Parts | 120.61102CRY |
| Centric Parts | 121.61102 |
| Centric Parts | 126.61102CSL |
| Centric Parts | 126.61102CSR |
| Centric Parts | 126.61102SL |
| Centric Parts | 126.61102SR |
| Centric Parts | 127.61102L |
| Centric Parts | 127.61102R |
| Centric Parts | 128.61102CL |
| Centric Parts | 128.61102CR |
| Centric Parts | 128.61102L |
| Centric Parts | 128.61102R |
| Centric Parts | 227.61102L |
| Centric Parts | 227.61102R |
| Centric Parts | 320.61102 |
| Centric Parts | 321.61102 |
| Dura Corp | BR54171 |
| DuraGo | BR901020 |
| DuraGo | BR90102002 |
| Motorcraft | NBRR12 |
| Newtek Automotive USA | 54171 |
| Parts Master | 901020 |
| PowerStop | AR8194EVC |
| PowerStop | AR85137EVC |
| Promax | 14-54171 |
| Qualis | 42278 |
| UAP | 2901020 |
| UAP | R61102 |
| Ultra Brake | 54515 |
| Wagner Brake | BD180285 |
| Wagner Brake | BD180462 |
| Wagner Brake | BD180462E |
Fits Years: 2011 2012 2013 2014 2015 2016 2017 2018 2019
Fits Models: Explorer
